Airtac F-JCK-AM Clamping Arm F-JCK40AM3C
AirTAC F-JCK-AM Clamping Arm F-JCK40AM3C Technical Specifications
- Model: F-JCK40AM3C
- Series: F-JCK-AM (Aluminum Mechanical Clamp)
- Clamping force: 200-400N (adjustable via air pressure)
- Stroke length: 40mm ±0.5mm
- Operating pressure: 0.2-0.7 MPa
- Repeat positioning accuracy: ±0.03mm
- Cylinder compatibility: SDA/SDB/SUD series Ø40mm bore
- Operating temperature: -10℃ to 80℃
- Surface treatment: Hard anodized aluminum body
- Seal material: NBR/PU hybrid seals
- Weight: 1.85kg ±2%
- Dimensions: 198mm(L) × 82mm(W) × 48mm(H)
- Mounting holes: 4×M6 threaded (8mm depth)
- Rod end thread: M10×1.25
- Shock absorption: Built-in polyurethane dampers
High-precision mechanical clamping arm with self-locking mechanism, featuring wear-resistant guide rails and precision ground surfaces (Ra0.8μm). The dual-V-slot design enables multi-directional positioning while maintaining ±0.01mm parallelism tolerance. Integrated T-slot allows modular accessory attachment.
- CNC machine tool fixture systems
- Automated welding positioners
- PCB assembly line component retention
- Robotic end-effector tool changing stations
- Optical inspection equipment positioning
Installation protocol:
Apply lithium-based grease to guide rails every 500,000 cycles.
Ensure pneumatic supply contains ≤25mg/m³ oil mist.
Torque mounting bolts to 8.8N·m ±10% using cross pattern tightening sequence.
| Property | Property Value |
|---|---|
| sku | F-JCK40AM3C |
| Clamping Arm Model Code | Offset 45mm |
| Bore Diameter | <40mm> |
