Airtac F-JCK-AM Clamping Arm F-JCK40AM3L
$37.19
Regular price
$44.69
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
F-JCK40AM3L
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
Category: Pneumatic Welding Clamping Cylinder | Brand: AirTAC | Series: F-JCK-AM Clamping Arm
Professional industrial terminology optimized translation preserves key parameters while concisely describing the product's functional attributes. The term "Pneumatic" explicitly indicates compressed air actuation method, "Clamping Arm" specifies the mechanical configuration, and the series nomenclature maintains original alphanumeric identification per manufacturer standards.
Operation guidance:
For optimal performance, lubricate guide rails with ISO VG32 hydraulic oil every 500,000 cycles.
Use torque wrench (4-5N·m) for clamp force adjustment. Avoid side-load exceeding 50N.
AirTAC F-JCK-AM Clamping Arm F-JCK40AM3L Technical Specifications
- Model: F-JCK40AM3L
- Type: Multi-position adjustable clamping arm
- Clamping force: 180-220N (adjustable via air pressure)
- Stroke length: 40mm (±2mm tolerance)
- Compatible cylinder series: AC/MY1B/MK series
- Repeat positioning accuracy: ±0.05mm
- Operating pressure: 0.3-0.7 MPa
- Body material: Anodized aluminum alloy (hard coat)
- Clamp pad material: NBR rubber with steel reinforcement
- Weight: 1.8kg (including mounting accessories)
- Dimensions: 158mm(L) × 62mm(W) × 85mm(H)
- Temperature resistance: -10℃ to 80℃
- Vibration resistance: ≤10 m/s² (ISO 10816-3)
- Mounting options: Horizontal/Vertical/Ceiling
Precision clamping arm with 3-axis micro-adjustment capability (±2° angular compensation), featuring wear-resistant linear guides and dual locking mechanism. The hexagonal shaft design prevents rotation during operation. Includes anti-vibration pads for high-speed applications.
Industrial Applications:
- CNC machine tool workpiece fixturing
- Automated welding station positioning
- PCB assembly line component retention
- Robotic arm end-effector tooling
- Optical lens polishing fixtures
Operation guidance:
For optimal performance, lubricate guide rails with ISO VG32 hydraulic oil every 500,000 cycles.
Use torque wrench (4-5N·m) for clamp force adjustment. Avoid side-load exceeding 50N.
Configuration options:
- Parallel clamp mode: 0-40mm stroke
- Toggle clamp mode: 20mm fixed position
- Manual fine-tuning range: ±5mm (X/Y axes)
| Property | Property Value |
|---|---|
| sku | F-JCK40AM3L |
| Clamping Arm Model Code | Offset 45mm |
| Bore Diameter | <40mm> |
