Airtac F-JCK-AM Clamping Arm F-JCK40AM3R
$37.19
Regular price
$44.69
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
F-JCK40AM3R
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
Category: Pneumatic Welding Clamping Cylinder | Brand: AirTAC | Series: F-JCK-AM Clamping Arm
Professional industrial terminology optimized translation preserves key parameters while concisely describing the product's functional attributes. The term "Pneumatic" explicitly indicates compressed air actuation method, "Clamping Arm" specifies the mechanical configuration, and the series nomenclature maintains original alphanumeric identification per manufacturer standards.
Installation protocol:
Apply 25-30N·m torque to mounting bolts. Lubricate guide rails with ISO VG32 hydraulic oil
during initial setup. Perform force calibration after 500 operating cycles.
Critical note:
Do NOT exceed 1.2MPa pressure. Use air dryer when ambient humidity exceeds 70% RH.
Replace shock absorber pads every 50,000 cycles.
AirTAC F-JCK-AM Clamping Arm F-JCK40AM3R Technical Details
- Model: F-JCK40AM3R
- Series: F-JCK-AM Modular Clamping System
- Clamping force: 4,000N (max at 0.6MPa)
- Stroke length: 40mm (±20mm adjustable)
- Operating pressure: 0.3–0.8 MPa
- Piston diameter: Ø40mm
- Rod thread: M16×1.5
- Weight: 2.85kg (bare unit), 3.2kg (with accessories)
- Dimensions: 180mm(L) × 85mm(W) × 62mm(H)
- Body material: Anodized aluminum alloy (A6063-T5)
- Seal type: HNBR high-temp seals
- Temperature range: -10℃ to 120℃
- Repeat accuracy: ±0.05mm
- Response time: 0.3s (actuation), 0.5s (release)
- Mounting: M6×1.0 threaded holes (4x)
- Accessory ports: G1/8 air inlet
Heavy-duty mechanical locking clamp arm with self-lubricating guides, designed for precision positioning in high-cycle applications. Features dual-chamber air cushioning and wear-compensation adjustment screws. Requires ISO 8573-1:2010 Class 3 compressed air.
Industrial Applications:
- Automotive welding fixture positioning
- CNC machining center pallet locking
- Die-casting mold clamping systems
- Robotic assembly station workholding
- Optical lens polishing equipment
Installation protocol:
Apply 25-30N·m torque to mounting bolts. Lubricate guide rails with ISO VG32 hydraulic oil
during initial setup. Perform force calibration after 500 operating cycles.
Critical note:
Do NOT exceed 1.2MPa pressure. Use air dryer when ambient humidity exceeds 70% RH.
Replace shock absorber pads every 50,000 cycles.
| Property | Property Value |
|---|---|
| sku | F-JCK40AM3R |
| Clamping Arm Model Code | Offset 45mm |
| Bore Diameter | <40mm> |
