Airtac F-JCK-AM Clamping Arm F-JCK50AM1L
AirTAC F-JCK-AM Clamping Arm F-JCK50AM1L Technical Specifications
- Model: F-JCK50AM1L (Complete assembly with integrated clamp)
- Clamping force: 1,960N @ 0.5MPa
- Stroke: 50mm ±0.5 (Maximum extension)
- Operating pressure: 0.15–0.7 MPa
- Rod end thread: M10×1.5 (Male)
- Repeat positioning accuracy: ±0.02mm
- Body material: Anodized aluminum alloy (A6063-T5)
- Slide mechanism: Linear ball bearing guide
- Surface hardness: HV400±20 (Hard coat anodized)
- Weight: 2.45kg (Including all mounting hardware)
- Dimensions: 218mm(L) × 78mm(W) × 54mm(H)
- Operating temperature: -10℃ to 80℃
- Lubrication: Pre-lubricated with Molykote EM-30L grease
- Protection class: IP54 (Dust/water spray resistant)
Heavy-duty mechanical clamping arm with zero-backlash ball guide system, designed for precision fixturing in CNC machining centers. Features dual locking mechanism with primary pneumatic actuation and secondary mechanical lock. Integrated shock absorbers minimize vibration during high-speed operations. Requires filtered air supply (5μm filtration recommended).
- Workpiece positioning in 5-axis CNC milling
- Automated welding jig systems
- Composite material trimming stations
- Precision optical component polishing
- Automotive transmission assembly lines
Installation protocol:
Mount on machined surface with flatness ≤0.02mm. Use 12.9 grade mounting bolts
torqued to 22±2 N·m. Perform alignment calibration after 500 operation cycles.
| Property | Property Value |
|---|---|
| sku | F-JCK50AM1L |
| Clamping Arm Model Code | Offset 15mm |
| Bore Diameter | <50mm> |
