Airtac F-JCK-AM Clamping Arm F-JCK50AM3C
$48.82
Regular price
$56.32
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
F-JCK50AM3C
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
Category: Pneumatic Welding Clamping Cylinder | Brand: AirTAC | Series: F-JCK-AM Clamping Arm
Professional industrial terminology optimized translation preserves key parameters while concisely describing the product's functional attributes. The term "Pneumatic" explicitly indicates compressed air actuation method, "Clamping Arm" specifies the mechanical configuration, and the series nomenclature maintains original alphanumeric identification per manufacturer standards.
Installation protocol:
Use M8 class 8.8 mounting bolts torqued to 22N·m. Maintain 0.5mm minimum
parallelism between clamp face and workpiece. Relubricate every 500,000 cycles
using silicone-free grease (ISO VG15 equivalent).
AirTAC F-JCK-AM Clamping Arm F-JCK50AM3C Technical Specifications
- Model: F-JCK50AM3C (Standard series with manual locking)
- Clamping force: 1,960N @ 0.5MPa
- Stroke range: 0-50mm (adjustable via precision scale)
- Operating pressure: 0.15–0.7 MPa
- Piston diameter: Ø50mm
- Rod thread: M12×1.75
- Body material: Anodized aluminum alloy (A6063-T5)
- Seal type: HNBR rubber with PTFE anti-friction coating
- Surface hardness: HV380±20 (hard anodized treatment)
- Weight: 2.8kg (with standard accessories)
- Dimensions: 178mm(L) × 85mm(W) × 72mm(H)
- Mounting pattern: ISO 15552 compliant
- Repeat accuracy: ±0.02mm
- Temperature range: -10℃ to 80℃
- Lubrication: Pre-lubricated (Molykote 33M)
Heavy-duty clamping mechanism featuring dual V-groove guidance for anti-rotation stability. Integrated torque limiter prevents over-clamping damage. The bright anodized surface resists coolant penetration, while the 360° visible position scale enables quick setup adjustments.
Industrial Applications:
- CNC machine tool workpiece fixturing
- Automotive welding jig positioning
- Precision mold alignment systems
- Semiconductor wafer handling robots
- Composite material press tooling
Installation protocol:
Use M8 class 8.8 mounting bolts torqued to 22N·m. Maintain 0.5mm minimum
parallelism between clamp face and workpiece. Relubricate every 500,000 cycles
using silicone-free grease (ISO VG15 equivalent).
| Property | Property Value |
|---|---|
| sku | F-JCK50AM3C |
| Clamping Arm Model Code | Offset 45mm |
| Bore Diameter | <50mm> |
