Airtac F-JCK-AM Clamping Arm F-JCK50AM3L
AirTAC F-JCK-AM Clamping Arm F-JCK50AM3L Technical Specifications
- Model: F-JCK50AM3L
- Series: F-JCK-AM Heavy Duty Clamp Unit
- Clamping force: 2,500 N (at 0.5 MPa)
- Stroke: 50mm ±0.5mm
- Operating pressure: 0.15–0.7 MPa
- Return spring force: 160 N
- Piston diameter: φ50mm
- Rod material: SCM435 hardened steel (HRC 38-42)
- Body material: Aluminum alloy ADC12 with hard anodizing
- Guide rod diameter: φ12mm (dual rods)
- Weight: 1.2 kg ±3%
- Dimensions: 215mm(L) × 72mm(W) × 64mm(H)
- Mounting hole pattern: 160mm × 40mm (M6 threaded holes)
- Operating temperature: -10℃ to 80℃
- Lubrication: Pre-lubricated (Grease G-46)
- Repeat positioning accuracy: ±0.05mm
- ISO Standard: 6432 compliant
High-precision clamping unit with dual hardened guide rods and anti-rotation mechanism, designed for repetitive heavy-load applications. Features wear-resistant composite seals (PU+NBR) and integrated shock absorbers. Requires 5μm filtered air with 1-3 drops of ISO VG32 oil per m³ for optimal performance.
- Robotic welding fixture positioning
- CNC machine tool workpiece clamping
- Automotive assembly line jig systems
- Optical lens polishing equipment
- Battery module compression testing
Installation guidelines:
Maintain parallel alignment within 0.2mm/m during mounting. Use torque-controlled fasteners (4.9-5.9 N·m for M6 bolts).
Perform stroke-end adjustment via hex socket before initial operation.
| Property | Property Value |
|---|---|
| sku | F-JCK50AM3L |
| Clamping Arm Model Code | Offset 45mm |
| Bore Diameter | <50mm> |
