Airtac F-JCK-AM Clamping Arm F-JCK50AM3R
AirTAC F-JCK-AM Clamping Arm F-JCK50AM3R Technical Specifications
- Model: F-JCK50AM3R
- Type: Compact parallel gripper with mechanical lock
- Clamping force: 50N (adjustable via pressure regulation)
- Stroke per jaw: 25mm (±12.5mm from center)
- Repeat accuracy: ±0.03mm
- Operating pressure: 0.1-0.7 MPa
- Material: Aluminum alloy body (A6061-T6) with hard anodized surface
- Guide mechanism: Dual linear ball bearings
- Mounting pattern: Compatible with MDBT50 series cylinders
- Weight: 1.25kg (excluding accessories)
- Dimensions: 198mm(L) × 52mm(W) × 34mm(H)
- Temperature range: -20℃ to +80℃
- Lubrication: Pre-lubricated with Molykote EM-30L grease
- Surface hardness: HV400±50
- Mounting holes: 4×M5 threaded (8mm depth)
Precision clamping arm featuring zero-point clamping capability and anti-vibration design. The hardened guide rails and dual ball bearing system ensure smooth operation with minimal stick-slip effect. Integrated T-slot on top allows modular tooling attachment. Requires clean dry air (40μm filtration) with recommended 1-3 cycles/sec operation.
- Robotic end-effector tool changing systems
- CNC machine fixture quick-change stations
- Automated inspection equipment positioning
- PCB handling in SMT production lines
- Medical device assembly automation
Installation note:
Maintain perpendicularity within 0.1mm/m during mounting. Apply thread locker (medium strength)
to M5 fasteners and torque to 2.5N·m ±10%. Avoid side load exceeding 30N during operation.
| Property | Property Value |
|---|---|
| sku | F-JCK50AM3R |
| Clamping Arm Model Code | Offset 45mm |
| Bore Diameter | <50mm> |
