Airtac F-JCK-AM Clamping Arm F-JCK50AM4C
$48.82
Regular price
$56.32
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
F-JCK50AM4C
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
Category: Pneumatic Welding Clamping Cylinder | Brand: AirTAC | Series: F-JCK-AM Clamping Arm
Professional industrial terminology optimized translation preserves key parameters while concisely describing the product's functional attributes. The term "Pneumatic" explicitly indicates compressed air actuation method, "Clamping Arm" specifies the mechanical configuration, and the series nomenclature maintains original alphanumeric identification per manufacturer standards.
Operational guidance:
Apply lithium-based grease to guide columns every 500,000 cycles.
Maximum side load capacity: 150N perpendicular to clamping axis.
Use shim plates when mounting on uneven surfaces.
AirTAC F-JCK-AM Clamping Arm F-JCK50AM4C Technical Specifications
- Model: F-JCK50AM4C
- Type: Guided rod clamping arm with manual lock
- Max clamping force: 500 N
- Stroke: 50 mm (±25mm adjustable)
- Rod diameter: Ø16 mm precision ground
- Operating pressure: 0.2–0.7 MPa
- Repeat positioning accuracy: ±0.03 mm
- Material: Anodized aluminum alloy body, hardened steel guide rods
- Weight: 2.8 kg (with standard accessories)
- Dimensions: 215mm(L) × 68mm(W) × 62mm(H)
- Mounting pattern: 50mm × 50mm ISO standard
- Temperature resistance: -10℃ to 80℃
- Surface finish: Hard oxidation 25μm (Aluminum parts)
Precision clamping mechanism with dual guide columns and anti-rotation design, featuring manual override capability for emergency adjustments. The nickel-plated steel base plate ensures corrosion resistance in humid environments. Includes integrated T-slot for sensor mounting.
Typical Applications:
- CNC machine tool fixture systems
- Automated welding positioners
- Optical inspection equipment clamping
- PCB assembly line pallet locking
- Robotic deburring station workholding
Operational guidance:
Apply lithium-based grease to guide columns every 500,000 cycles.
Maximum side load capacity: 150N perpendicular to clamping axis.
Use shim plates when mounting on uneven surfaces.
| Property | Property Value |
|---|---|
| sku | F-JCK50AM4C |
| Clamping Arm Model Code | Offset 45mm |
| Bore Diameter | <50mm> |
