Airtac F-JCK-AM Clamping Arm F-JCK50AM4L
AirTAC F-JCK-AM Clamping Arm F-JCK50AM4L Technical Specifications
- Full model number: F-JCK50AM4L
- Clamping force: 500N (adjustable via pressure regulation)
- Stroke length: 40±0.5mm
- Operating pressure range: 0.2-0.7 MPa
- Compatible cylinder series: SC/SU/SI 50mm bore
- Arm material: Anodized aluminum alloy (AL6061-T6)
- Surface hardness: HV 400±50
- Pivot bearing type: Stainless steel needle roller bearing
- Clamp jaw opening: 25-50mm (manual adjustment)
- Repeat positioning accuracy: ±0.05mm
- Operating temperature: -10℃ to 80℃
- Weight: 2.8kg (with standard fittings)
- Dimensions: 248mm(L) × 76mm(W) × 152mm(H)
- Mounting pattern: ISO 15552 standard 50mm spacing
- Seal material: HNBR (hydrogenated nitrile) for high temperature resistance
Heavy-duty mechanical clamping arm with precision ground guide rods and dual-stage locking mechanism. Features anti-vibration design with integrated shock absorption pads (Shore A 70±5). Includes M8 pre-lubricated air ports and adjustable cushioning screws for motion control. Requires 5μm filtered air with ISO VG32 hydraulic oil mist lubrication.
- CNC machine tool workpiece fixturing
- Automotive welding line component positioning
- Die-casting mold clamping during ejection cycles
- PCB assembly conveyor stopping mechanisms
- Robotic arm end-effector tool changing stations
Maintenance protocol:
Apply MIL-PRF-81309 grease quarterly to pivot points.
Maximum side load capacity: 150N. For vertical installations,
use model-specific counterbalance kit (F-JCK-VMK50).
| Property | Property Value |
|---|---|
| sku | F-JCK50AM4L |
| Clamping Arm Model Code | Offset 45mm |
| Bore Diameter | <50mm> |
