Airtac F-JCK-AM Clamping Arm F-JCK50AM4R
AirTAC F-JCK-AM Clamping Arm F-JCK50AM4R Technical Specifications
- Model: F-JCK50AM4R
- Type: 4-jaw parallel gripper arm (manual clamping)
- Clamping force: 50N (adjustable via torque limiter)
- Stroke per jaw: ±2.5mm
- Compatible cylinder series: AIRTAC SC/SU/MA series
- Material: Anodized aluminum alloy (AA6061-T6)
- Surface hardness: HV 400-450
- Operating temperature: -20℃ to 80℃
- Repeat positioning accuracy: ±0.02mm
- Mounting pattern: ISO 9409-1-25-4-M6 (standardized interface)
- Compatible shaft diameter: φ4-φ6mm
- Weight: 320g ±5%
- Dimensions: 78mm(L) × 42mm(W) × 34mm(H)
Precision-engineered manual clamping arm with anti-vibration design, featuring chromium-plated guide rods and self-lubricating bronze bushings. The F-JCK50AM4R incorporates a failsafe locking mechanism with 4-point contact surface treatment (micro-arc oxidation) for particle resistance in cleanroom environments. Requires periodic lubrication every 50,000 cycles using ISO VG32 hydraulic oil.
- PCB handling in SMT production lines
- Precision optical component alignment
- Medical device assembly stations
- Robotic end-effector tool changing systems
- Semiconductor wafer transfer mechanisms
Installation protocol:
Mount using M4×8mm SHCS (max torque 1.2N·m) with 0.02mm parallelism tolerance.
Apply 3-5μm molybdenum disulfide coating on sliding surfaces during maintenance.
- Works with ISO 6432 standard cylinders
- Adaptable to MISUMI HFS5/HFL5 rail systems
- Requires 0.05-0.7MPa clean dry air supply
- Max lateral load capacity: 15N (perpendicular to clamping axis)
| Property | Property Value |
|---|---|
| sku | F-JCK50AM4R |
| Clamping Arm Model Code | Offset 45mm |
| Bore Diameter | <50mm> |
