Airtac F-JCK-AM Clamping Arm F-JCK63AM1R
AirTAC F-JCK-AM Clamping Arm F-JCK63AM1R Technical Specifications
- Model: F-JCK63AM1R
- Type: Compact parallel gripper clamping arm
- Clamping force: 63N (at 0.5MPa)
- Actuator stroke: 10mm ±0.5mm
- Compatible cylinder series: MAL/MALH 16-32
- Mounting hole spacing: 30mm (center-to-center)
- Material: Aluminum alloy (anodized surface)
- Operating pressure: 0.1-0.7 MPa
- Temperature range: -20℃ to +80℃
- Repeat positioning accuracy: ±0.05mm
- Weight: 0.85kg
- Dimensions: 80mm(L) × 60mm(W) × 30mm(H)
- Surface hardness: HV400±50
- Rod thread: M6×1.0
High-precision clamping arm with self-lubricating guide mechanism, designed for repetitive gripping tasks in automated systems. Features dual V-groove alignment for secure workpiece positioning and anti-vibration design for high-speed applications. Compatible with ISO 6432 standard cylinders.
- CNC machine tool workpiece fixation
- Robotic arm end-effector tooling
- PCB handling in SMT production lines
- Precision gear assembly systems
- Automated optical inspection (AOI) fixtures
Installation guidance:
Apply Loctite 243 to mounting screws (recommended torque 3.5N·m).
Maintain 0.1-0.2mm clearance between clamping jaws and workpiece
surface during initial alignment. Lubricate guide rails monthly
with ISO VG32 hydraulic oil.
- Jaw plates: F-JCP-6S (standard), F-JCP-6H (hardened)
- Mounting kits: F-JCM-16B (M4 fasteners included)
- Position sensors: APSE-8P (non-contact magnetic type)
| Property | Property Value |
|---|---|
| sku | F-JCK63AM1R |
| Clamping Arm Model Code | Offset 15mm |
| Bore Diameter | 63mm |
