Airtac F-JCK-AM Clamping Arm F-JCK63AM2C
AirTAC F-JCK-AM Clamping Arm F-JCK63AM2C Technical Specifications
- Full model designation: F-JCK63AM2C
- Clamping force range: 100-650N (adjustable via pressure regulation)
- Stroke length: 20±1mm
- Compatible cylinder series: SC/SU 32-100mm bore sizes
- Clamp arm material: Hard-anodized aluminum alloy (A6063-T5)
- Pivot bearing type: Sealed ball bearings (IP54 protection)
- Operating pressure: 0.15-0.7 MPa
- Temperature tolerance: -10℃ to 80℃
- Surface hardness: HV 400±20 (contact surfaces)
- Repeat positioning accuracy: ±0.03mm
- Weight: 1.85kg ±5%
- Dimensions: 178mm(L) × 86mm(W) × 63mm(H)
- Mounting pattern: ISO 15552 compliant 32mm center spacing
Precision-engineered clamping mechanism with self-locking wedge design, featuring dual-stage force amplification through optimized lever ratio. The hardened contact surfaces and PTFE-impregnated bushings ensure smooth operation over 500,000 cycles. Includes M6 threaded mounting points for tooling customization.
- CNC machine tool workpiece fixturing
- Robotic welding cell part positioning
- Automotive engine component assembly stations
- Pharmaceutical blister packaging machinery
- Semiconductor wafer handling systems
Installation protocol:
Lubricate guide shafts with ISO VG32 hydraulic oil before initial operation.
Maintain 0.5-0.7mm clearance between clamp jaw and workpiece surface.
Maximum side load capacity: 200N (perpendicular to clamping direction).
| Property | Property Value |
|---|---|
| sku | F-JCK63AM2C |
| Clamping Arm Model Code | Offset 15mm |
| Bore Diameter | 63mm |
