Airtac F-JCK-AM Clamping Arm F-JCK63AM2R
AirTAC F-JCK-AM Clamping Arm F-JCK63AM2R Technical Details
- Model: F-JCK63AM2R (AM series with right-hand thread)
- Type: Mechanical toggle clamping arm
- Clamping force: 800N ±10% @0.5MPa
- Stroke adjustment: ±5mm (fine-tuned via threaded rod)
- Operating pressure: 0.2-0.7 MPa
- Compatible cylinder bore: φ63mm (optimized for AIRTAC SC/SU series)
- Material:
- Main body: Aluminum alloy ADC12 (hard anodized)
- Claw tips: SK5 carbon steel (HRC45±2 hardness)
- Pivot bearings: Chrome steel GCr15
- Repeat positioning accuracy: ≤±0.02mm
- Mounting orientation: Horizontal/vertical (side or top mounting)
- Weight: 3.2kg ±5% (excluding mounting hardware)
- Dimensions: 150mm(L) × 85mm(W) × 65mm(H)
- Surface treatment: Black electrophoretic coating (8-12μm thickness)
- Temperature resistance: -20℃ to 120℃ (lubricated condition)
- Lubrication interval: 500,000 cycles (using ISO VG32 hydraulic oil)
Heavy-duty clamping mechanism with self-locking toggle design, featuring dual-stage force amplification through precision-machined linkage system. The hardened steel contact surfaces withstand repeated impact loads, while the modular structure allows 180° claw rotation for multi-position workpiece handling. Requires 40μm filtered air supply with 1-3% lubricating oil mist concentration.
- CNC machining center fixture systems
- Automotive welding jig positioning
- Die-casting mold clamping during ejection
- PCB depaneling machine workholding
- Robotic arm end-effector tooling
Operation guidance:
Pre-load adjustment should maintain 0.5-1mm gap between claw and workpiece before activation.
Avoid side impacts exceeding 300N. Monthly inspect pivot pin wear using GO/NOGO gauge (included in maintenance kit).
- Direct mounting: SC63×25/50/75-SU cylinders
- Adaptable to ISO 15552 rail systems with AM-CA63 adapter
- Maximum workpiece thickness: 50mm (extendable to 80mm with spacer kit AM-SP63)
| Property | Property Value |
|---|---|
| sku | F-JCK63AM2R |
| Clamping Arm Model Code | Offset 15mm |
| Bore Diameter | 63mm |
