Airtac F-JCK-AM Clamping Arm F-JCK63AM3C
AirTAC F-JCK-AM Clamping Arm F-JCK63AM3C Technical Specifications
- Model: F-JCK63AM3C
- Type: Multi-position adjustable clamping arm
- Compatible cylinder bore: Ø63mm (optimized for ADA/ADQ series)
- Clamping force: 280-320N (adjustable via air pressure)
- Stroke length: 25mm ±0.5mm
- Operating pressure: 0.2-1.0 MPa
- Pivot rotation: ±5° angular compensation
- Mounting holes: 4×M6 threaded (8mm depth)
- Surface treatment: Hard anodized (HV400)
- Weight: 1.45kg ±2%
- Dimensions: 148mm(L) × 78mm(W) × 42mm(H)
- Material: Aerospace-grade aluminum alloy (6061-T6)
- Temperature resistance: -30℃ to 120℃
- Vibration resistance: ≤15Hz @ 2mm amplitude
- Repeat positioning accuracy: ±0.02mm
Precision-engineered clamping arm with dual guide rods and anti-backlash mechanism, featuring tungsten-carbide tipped jaws for secure workpiece retention. Integrated T-slot design allows tooling plate compatibility. Includes corrosion-resistant PTFE-impregnated bushings for maintenance-free operation.
- CNC machine tooling fixture systems
- Robotic welding cell position locking
- Automotive engine component assembly
- High-speed PCB testing equipment
- Pharmaceutical blister packaging lines
Installation protocol:
Always preload clamping mechanism at 20% above operational pressure during initial setup.
Lubricate guide rods with ISO VG32 hydraulic oil monthly. Avoid side-load exceeding 50N.
| Property | Property Value |
|---|---|
| sku | F-JCK63AM3C |
| Clamping Arm Model Code | Offset 45mm |
| Bore Diameter | 63mm |
