Airtac F-JCK-AM Clamping Arm F-JCK63AM4C
AirTAC F-JCK-AM Clamping Arm F-JCK63AM4C Technical Specifications
- Model: F-JCK63AM4C
- Type: Multi-position precision clamping arm
- Clamping force: 1,200N (max @ 0.6MPa)
- Stroke: 15mm (adjustable)
- Clamping diameter range: 5-63mm
- Repeat accuracy: ±0.02mm
- Operating pressure: 0.3-0.7MPa
- Material: Anodized aluminum alloy body, hardened steel jaws
- Weight: 2.4kg (with standard fittings)
- Dimensions: 178mm(L) × 85mm(W) × 65mm(H)
- Temperature range: -10℃ to 80℃
- Surface hardness: HV450 (jaw contact surfaces)
- Mounting pattern: ISO 15552 compliant
- Vibration resistance: ≤5G (15-2000Hz)
Heavy-duty modular clamping solution featuring dual-acting pneumatic control and wear-compensating jaw design. Incorporates anti-vibration pads and precision ground guide rods for stable operation in high-cycle applications. Requires filtered (5μm), lubricated air supply (ISO VG32 recommended).
- CNC machine tool fixture systems
- Automotive transmission component assembly
- Robotic welding position locking
- Optical lens polishing equipment
- PCB depaneling machine workholding
Installation guidance:
Mount on rigid structural surfaces using M8×1.25 bolts (4 required) with
≤0.02mm flatness tolerance. Perform jaw alignment calibration after every
50,000 cycles using included shim set.
| Property | Property Value |
|---|---|
| sku | F-JCK63AM4C |
| Clamping Arm Model Code | Offset 45mm |
| Bore Diameter | 63mm |
