Airtac F-JCK-AM Clamping Arm F-JCK63AM4R
$48.82
Regular price
$56.32
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
F-JCK63AM4R
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
Category: Pneumatic Welding Clamping Cylinder | Brand: AirTAC | Series: F-JCK-AM Clamping Arm
Professional industrial terminology optimized translation preserves key parameters while concisely describing the product's functional attributes. The term "Pneumatic" explicitly indicates compressed air actuation method, "Clamping Arm" specifies the mechanical configuration, and the series nomenclature maintains original alphanumeric identification per manufacturer standards.
Installation notes:
1. Lubricate guide rails with ISO VG32 hydraulic oil before initial use
2. Maintain 0.3-0.5mm clearance between clamping jaws and workpiece
3. Recommended maintenance interval: 500,000 cycles or 6 months
AirTAC F-JCK-AM Clamping Arm F-JCK63AM4R Technical Specifications
- Model: F-JCK63AM4R (Enhanced clamping series)
- Clamping force: 630N ±10% @0.5MPa
- Stroke: 15mm (adjustable)
- Repeat accuracy: ±0.05mm
- Operating pressure: 0.2-0.7MPa
- Air consumption: 1.5L/min (ANR)
- Rod material: Chrome-plated steel (HRC45-50)
- Body material: Anodized aluminum alloy
- Seal type: NBR + PU hybrid seals
- Temperature range: -10℃ to 80℃
- Mounting pattern: ISO 15552 compliant
- Weight: 1.8kg (including accessories)
- Dimensions: 198mm(L) × 85mm(W) × 62mm(H)
High-precision clamping arm with self-locking mechanism, featuring anti-vibration design for industrial automation. The dual-guide rail structure ensures parallel movement under heavy loads. Includes integrated shock absorbers and wear compensation adjustment screws.
Typical Applications:
- CNC machine tooling fixture systems
- Robotic welding arm end effectors
- Automotive assembly line positioning
- PCB handling in SMT production lines
- Pharmaceutical packaging equipment
Installation notes:1. Lubricate guide rails with ISO VG32 hydraulic oil before initial use
2. Maintain 0.3-0.5mm clearance between clamping jaws and workpiece
3. Recommended maintenance interval: 500,000 cycles or 6 months
| Property | Property Value |
|---|---|
| sku | F-JCK63AM4R |
| Clamping Arm Model Code | Offset 45mm |
| Bore Diameter | 63mm |
