Airtac F-JCK-LM Adjustment Screw F-JCK40X105LM
AirTAC F-JCK-LM Adjusting Screw F-JCK40X105LM Technical Details
- Full model designation: F-JCK40X105LM
- Series: F-JCK-LM precision adjustment series
- Thread specification: M40×1.5 fine pitch metric thread
- Material: Carbon steel SCr420 with surface hardening
- Surface treatment: Electroless nickel plating (5-8μm)
- Effective adjustment range: ±3.5mm
- Maximum torque capacity: 120 N·m
- Locking nut torque: 18-22 N·m (pre-installed)
- Operating temperature: -30℃ to 120℃
- Weight: 450g ±2%
- Dimensions: 105mm(L) × 40mm(Φ) × 40mm(Hex width)
- Hex size: 40mm AF (across flats)
- Hardness: 58-62 HRC at contact surfaces
- Corrosion resistance: 96hrs salt spray test compliant
Precision-ground mechanical adjustment screw with anti-backlash design, featuring chromium-molybdenum alloy construction for heavy-duty industrial applications. The diamond-cut threading ensures smooth micrometer-level adjustments, while the integrated locking flange prevents unintended positional drift during operation.
- CNC machine tool backlash compensation systems
- Robotic arm joint tension calibration
- Hydraulic press parallel alignment adjustment
- Semiconductor wafer stage positioning
- Wind turbine pitch control mechanisms
Installation protocol:
Apply Molykote G-rapid lubricant on threads before initial use.
Use 40mm combination wrench for adjustment while tightening
counter-rotational locknut. Re-torque after 50 operating cycles.
| Property | Property Value |
|---|---|
| sku | F-JCK40X105LM |
| Bore Diameter | <40mm> |
| Adjustment Angle | 105° |
