Airtac F-JCK-LM Adjustment Screw F-JCK40X120LM
AirTAC F-JCK-LM Adjusting Screw F-JCK40X120LM Technical Details
- Full Model: F-JCK40X120LM
- Series: Fine Adjustment Screw (Locking Mechanism Type)
- Material: Carbon Steel SCr420 with Nickel Plating
- Thread Specification: M40×1.5 Metric Fine Thread
- Effective Adjustment Range: ±5° Angular Compensation
- Total Length: 120mm ±0.2mm
- Shank Diameter: 40mm (Precision Ground ±0.01mm)
- Locking Torque: 12-15 N·m (Pre-set at Factory)
- Surface Hardness: HRC 52-56
- Operating Temperature: -30℃ to 120℃
- Corrosion Resistance: 96hrs Neutral Salt Spray Test Pass
- Weight: 485g ±10g
- Dimensions: 120mm(L) × 40mm(Dia.) × 62mm(Hex Width)
Precision-engineered adjustment screw with integrated locking flange, designed for micron-level positional calibration in high-vibration environments. Features wear-resistant dual-contact surfaces and anti-backlash design. Includes Teflon-impregnated thread coating for smooth operation.
- CNC machine tool head alignment systems
- Robotic arm joint tension calibration
- Hydraulic press parallelism adjustment
- Semiconductor wafer stage leveling
- Wind turbine pitch control mechanisms
Installation protocol:
Apply MIL-PRF-81309F grease during assembly. Torque sequence:
1) Finger-tighten until contact 2) Apply 5 N·m pre-load 3) Final torque
to 12-15 N·m using dial indicator wrench. Re-torque after 24hrs run-in.
- For use with AIRTAC AJB40 series linear guides
- Compatible with AFM60-XYZ alignment fixtures
- Requires SCM-4K calibration module for precision setups
| Property | Property Value |
|---|---|
| sku | F-JCK40X120LM |
| Bore Diameter | <40mm> |
| Adjustment Angle | 120° |
