Airtac F-JCK-LM Adjustment Screw F-JCK40X135LM
AirTAC F-JCK-LM Adjustment Screw F-JCK40X135LM Technical Details
- Full model designation: F-JCK40X135LM
- Thread specification: M40×1.5 metric fine thread
- Total length: 135±0.2mm
- Effective thread length: 65mm
- Material: Aluminum alloy 6061-T6 with black anodized finish
- Hex wrench size: 8mm (for adjustment)
- Lock nut torque range: 12-15 N·m
- Operating temperature: -30℃ to 120℃
- Surface hardness: HV 400-450
- Weight: 328±5g (including lock nut)
- Dimensions: 40mm(dia) × 135mm(L)
- Corrosion resistance: 96hrs salt spray test passed
- Radial runout tolerance: ≤0.02mm
Precision-machined micro-adjustment screw with dual-stage locking mechanism, featuring anti-backlash design for stable positional maintenance. The diamond-turned contact surface (Ra 0.8μm) ensures minimal friction during fine adjustments. Compatible with ISO 4029 standards for adjustment elements.
- Z-axis calibration in CNC tooling fixtures
- Optical platform leveling systems
- Robotic end effector position fine-tuning
- Semiconductor wafer stage alignment
- Precision mold cavity depth adjustment
Installation protocol:
Apply thread locking compound (Loctite 243 recommended) to lower threads before final torque application.
Perform clockwise rotation for compression adjustments with maximum 180° incremental turns.
Avoid overtightening beyond 18N·m to prevent thread deformation.
| Property | Property Value |
|---|---|
| sku | F-JCK40X135LM |
| Bore Diameter | <40mm> |
| Adjustment Angle | 130° |
