Airtac F-JCK-LM Adjustment Screw F-JCK40X15LM
$6.94
Regular price
$14.44
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
F-JCK40X15LM
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
Product Category: Welding Clamping Cylinder
Brand: AirTAC
Series: F-JCK-LM Adjusting Screw
A precision-engineered pneumatic actuation component designed for welding fixture applications. The F-JCK-LM series features a robust threaded adjustment mechanism with fine-tuning capability for precise stroke control and position calibration in automated welding systems. Its hardened steel construction ensures wear resistance under high-cycle operations, while the anti-corrosion surface treatment guarantees performance stability in harsh industrial environments. Integrated with standardized mounting interfaces (ISO 6432 compliant) for seamless integration with welding jigs and robotic arms. Optional locking nut configuration prevents unintended positional drift during continuous vibration exposure. Typical applications include spot welding positioners, assembly line clamping fixtures, and CNC welding automation setups.
Mounting guidance:
Apply lithium-based grease to threads before installation.
Use 17mm thin wrench for locknut operation.
Perform torque calibration every 5,000 adjustment cycles.
AirTAC F-JCK-LM Adjusting Screw F-JCK40X15LM Technical Details
- Full model: F-JCK40X15LM
- Series: F-JCK-LM precision adjustment series
- Thread specification: M40×1.5
- Effective travel: 15mm ±0.5mm
- Total length: 65mm (including adjustment knob)
- Body diameter: 40mm (hexagon flat-to-flat)
- Material: Stainless steel SS304 (alternative: hardened carbon steel SCr420)
- Surface treatment: Electroless nickel plating (8-12μm thickness)
- Weight: 0.28kg ±3%
- Dimensions: 65mm(L) × 40mm(W) × 40mm(H)
- Axial load capacity: Max 2,500N (static), 1,800N (dynamic)
- Adjustment torque: 3-5N·m recommended
- Operating temperature: -20℃ to 120℃
- Vibration resistance: ≤15m/s² (frequency 10-55Hz)
- Protection class: IP54 (standard sealing)
Precision-ground micrometer-style adjustment screw with locknut mechanism, featuring anti-backlash design for stable positioning. The dual-helix thread pattern ensures smooth linear motion with 0.01mm repeatability. Includes integrated rubber O-ring (NBR material) for dust prevention.
Implementation Scenarios:
- CNC machine tool backlash compensation systems
- Injection molding machine platen parallelism adjustment
- Robotic end-effector fine positioning
- Optical equipment focus mechanism calibration
- Conveyor belt tensioning systems
Mounting guidance:
Apply lithium-based grease to threads before installation.
Use 17mm thin wrench for locknut operation.
Perform torque calibration every 5,000 adjustment cycles.
Mating components:
Compatible with AIRTAC SDA/SCD series cylinders.
Requires MJK-L40 adapter for ISO 12240-2 standard rod ends.
| Property | Property Value |
|---|---|
| sku | F-JCK40X15LM |
| Bore Diameter | <40mm> |
| Adjustment Angle | 15° |
