Airtac F-JCK-LM Adjustment Screw F-JCK40X45LM
AirTAC F-JCK-LM Adjustment Screw F-JCK40X45LM Technical Details
- Full Model Number: F-JCK40X45LM
- Series: Fine-thread Precision Adjustment Series
- Material: Carbon steel with nickel plating (SCM435 equivalent)
- Thread Specification: M40×1.5 (Metric coarse thread)
- Effective Adjustment Stroke: 45±0.5mm
- Torque Range: 50-300 N·m (Requires calibrated torque wrench)
- Surface Hardness: HRC 28-32 after heat treatment
- Mounting Orientation: Omnidirectional (vertical/horizontal)
- Temperature Tolerance: -30℃ to 120℃
- Corrosion Resistance: 96hrs salt spray test compliant
- Weight: 320g ±5% (including locking nut)
- Dimensions:
- Total Length: 78mm
- Threaded Shank Diameter: 40mm
- Hexagon Wrench Size: 19mm (for adjustment)
- Base Flange Height: 12mm
Precision-ground adjustment screw with anti-backlash design, featuring hardened contact surfaces and wear-indicator grooves. The dual-stage sealing (O-ring + thread sealant) ensures dust-proof operation in ISO 8573-1 Class 3 environments. Requires periodic lubrication with ISO VG32 hydraulic oil.
- Pneumatic cylinder stroke micro-adjustment in assembly lines
- Conveyor belt tensioning systems
- Injection molding machine platen parallelism correction
- CNC tooling fixture position calibration
- Semiconductor wafer handling robot Z-axis fine-tuning
Maintenance Protocol:
Apply thread anti-seize compound (copper-based) during installation.
Re-torque after first 50 operating hours. Replace when wear marks exceed
0.2mm depth on indicator grooves.
| Property | Property Value |
|---|---|
| sku | F-JCK40X45LM |
| Bore Diameter | <40mm> |
| Adjustment Angle | <45 degrees> |
