Airtac F-JCK-LM Adjustment Screw F-JCK40X60LM
AirTAC F-JCK-LM Adjustment Screw F-JCK40X60LM Technical Details
- Full model designation: F-JCK40X60LM
- Type: Precision mechanical adjustment screw with locking mechanism
- Thread specification: M8×1.25 (metric fine thread)
- Effective adjustment range: ±2mm
- Maximum torque capacity: 3-5 N·m
- Material composition: Carbon steel core with zinc-plated surface
- Surface treatment: Electro-galvanized (5-8μm coating thickness)
- Operating temperature: -30℃ to +120℃
- Vibration resistance: ≤50 m/s² (10-1500 Hz frequency range)
- Weight: 85±3 grams
- Dimensions: 40mm(D) × 25mm(Flange Width) × 60mm(Total Length)
- Compatibility: Designed for AIRTAC F-series linear guides & actuators
High-precision micro-adjustment component featuring a dual-stage locking system with anti-backlash design. The diamond-knurled grip surface ensures secure manual operation even in oily conditions. Incorporates a wear-compensating thread design that maintains positional accuracy through 50,000+ adjustment cycles.
- Precision alignment of pneumatic cylinder end stops
- Z-axis calibration in CNC tooling fixtures
- Conveyor belt tension adjustment mechanisms
- Robotic end effector position fine-tuning
- Optical equipment focus adjustment assemblies
Installation protocol:
Apply lithium-based grease to threads before initial use.
Always perform final tightening with calibrated torque wrench -
exceed 5N·m may deform locking collet. Re-calibrate every 6 months
in high-cycle applications (＞200 ops/day).
| Property | Property Value |
|---|---|
| sku | F-JCK40X60LM |
| Bore Diameter | <40mm> |
| Adjustment Angle | <60°> |
