Airtac F-JCK-LM Adjustment Screw F-JCK40X75LM
$6.94
Regular price
$14.44
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
F-JCK40X75LM
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
Product Category: Welding Clamping Cylinder
Brand: AirTAC
Series: F-JCK-LM Adjusting Screw
A precision-engineered pneumatic actuation component designed for welding fixture applications. The F-JCK-LM series features a robust threaded adjustment mechanism with fine-tuning capability for precise stroke control and position calibration in automated welding systems. Its hardened steel construction ensures wear resistance under high-cycle operations, while the anti-corrosion surface treatment guarantees performance stability in harsh industrial environments. Integrated with standardized mounting interfaces (ISO 6432 compliant) for seamless integration with welding jigs and robotic arms. Optional locking nut configuration prevents unintended positional drift during continuous vibration exposure. Typical applications include spot welding positioners, assembly line clamping fixtures, and CNC welding automation setups.
Maintenance protocol:
Apply lithium-based grease (NLGI #2) to threads every 2,000 cycles.
Use torque wrench for re-tightening - do not exceed 18N·m.
Avoid chemical contact with chlorinated solvents.
AirTAC F-JCK-LM Adjusting Screw F-JCK40X75LM Technical Details
- Full Model: F-JCK40X75LM
- Series: F-JCK-LM Fine Adjustment Series
- Material: Chrome-plated carbon steel (SCM435 equivalent)
- Thread Size: M40×1.5 (coarse pitch metric thread)
- Effective Length: 75±0.2mm
- Adjustment Range: ±3 full rotations (total 4.5mm linear travel)
- Locking Torque: 12-15 N·m (pre-set at factory)
- Temperature Range: -30℃ to 120℃ (dry environment)
- Surface Hardness: HRC 28-32 (core), HV 500+ (surface)
- Anti-Corrosion: Triple-layer nickel plating (8-12μm thickness)
- Weight: 285g ±5g
- Dimensions: Ø40mm (knurled head) × 75mm (threaded shaft)
- Mounting: Compatible with M40 internal threaded ports
- Accessory: Includes 2.5mm hex key for calibration
Precision mechanical adjuster with graduated micrometer-style markings (0.25mm per division) for repeatable positioning. Features double-locking mechanism - spring-loaded friction lock plus secondary jam nut. Rated for 50,000+ adjustment cycles with ≤0.02mm positional drift.
Industrial Applications:
- Pneumatic cylinder stroke end-stop calibration
- Injection molding machine platen parallelism adjustment
- CNC tooling fixture micro-positioning
- Conveyor belt tensioning systems
- Semiconductor wafer stage vertical alignment
Maintenance protocol:
Apply lithium-based grease (NLGI #2) to threads every 2,000 cycles.
Use torque wrench for re-tightening - do not exceed 18N·m.
Avoid chemical contact with chlorinated solvents.
| Property | Property Value |
|---|---|
| sku | F-JCK40X75LM |
| Bore Diameter | <40mm> |
| Adjustment Angle | 75° |
