Airtac F-JCK-LM Adjustment Screw F-JCK40X90LM
AirTAC F-JCK-LM Series Adjustment Screw F-JCK40X90LM Technical Details
- Model: F-JCK40X90LM
- Type: Precision stroke adjustment screw with locknut
- Material: Carbon steel (SCM435 equivalent)
- Surface treatment: Black oxide coating (5-8μm)
- Thread specification: M40×1.5 fine pitch
- Effective length: 90±0.2mm
- Adjustment range: ±5mm stroke control
- Weight: 328g ±5g (including locknut)
- Dimensions:
- Total length: 90mm
- Threaded portion length: 45mm
- Hex size: 19mm (wrench flat-to-flat)
- Locknut diameter: 46mm
- Operating torque: 15-20 N·m (recommended installation torque)
- Temperature resistance: -30℃ to 120℃
- Corrosion resistance: 96hrs neutral salt spray test passed
- Compatible cylinder series: SDA/SI/SU/MAL/MF1
High-precision mechanical stop screw designed for pneumatic cylinder stroke adjustment and position locking. Features anti-vibration double-lock structure with integrated steel washer and nylon insert nut. The knurled grip surface ensures tool-free micro-adjustments during maintenance. Hardened surface (HV450) prevents thread deformation under repeated impacts.
- Position calibration in automated assembly lines
- Shock absorption adjustment for punch press cylinders
- End-of-arm tooling position fine-tuning in robotics
- Packaging machine stopper mechanism optimization
- Hydraulic system backup mechanical override
Installation protocol:
Apply medium-strength thread locker (Loctite 243 recommended) on clean threads before final torque application.
Perform clockwise rotation for extension, counter-clockwise for retraction. Re-torque after 50 operating cycles.
| Property | Property Value |
|---|---|
| sku | F-JCK40X90LM |
| Bore Diameter | <40mm> |
| Adjustment Angle | <90°> |
