Airtac F-JCK-LM Adjustment Screw F-JCK50X105LM
AirTAC F-JCK-LM Adjustment Screw F-JCK50X105LM Technical Details
- Full model: F-JCK50X105LM
- Type: Fine adjustment screw with lock mechanism
- Material: Carbon steel (SCM435) with nickel plating
- Thread size: M5×0.8 pitch
- Effective length: 105±0.3mm
- Adjustment range: ±2.5mm per full rotation
- Locking torque: 0.4-0.6 N·m (3.5-5.3 lbf·in)
- Operating temperature: -30℃ to 120℃
- Surface hardness: HV450-550
- Weight: 34.7g ±0.5g
- Dimensions: 105mm(L) × Φ10mm(Dia) × 6mm(Hex head height)
- Compatible tools: 5mm hex key (included in full kit)
Precision-ground adjustment screw with dual-stage locking mechanism for micron-level positioning in vibration-prone environments. Features wear-resistant chromium-molybdenum alloy core with anti-corrosion coating. The reverse-thread locking collar prevents accidental displacement during operation.
- Linear guide preload adjustment in CNC machines
- Conveyor belt tensioning systems
- Robotic arm end effector alignment
- Optical instrument focus mechanisms
- Die height calibration in stamping presses
Maintenance protocol:
Apply lithium-based grease (ISO-L-XBCHB2) every 50,000 cycles.
Maximum side load capacity: 245N. Always engage lock nut after final adjustment.
| Property | Property Value |
|---|---|
| sku | F-JCK50X105LM |
| Bore Diameter | <50mm> |
| Adjustment Angle | 105° |
