Airtac F-JCK-LM Adjustment Screw F-JCK50X15LM
AirTAC F-JCK-LM Adjustment Screw F-JCK50X15LM Technical Specifications
- Model: F-JCK50X15LM
- Type: Precision micro-adjustment screw with locking mechanism
- Material: Stainless steel (SUS303) with nickel plating
- Thread specification: M50×1.5 pitch
- Effective stroke: 15mm ±0.2mm
- Adjustment torque: 0.5-3.5 N·m (recommended operational range)
- Surface hardness: HRC 28-32
- Temperature resistance: -30℃ to 120℃
- Protection class: IP54 (dust/water resistant)
- Weight: 112g ±3g
- Dimensions: 50mm (Dia.) × 32mm (Base Height) × 65mm (Total Length)
- Mounting thread depth: 20mm
- Locking nut torque: 8-10 N·m
High-precision adjustment screw designed for micron-level positioning in pneumatic systems. Features dual-stage anti-loosening structure with secondary locking nut and integrated O-ring (NBR material) for vibration resistance. The chromium-plated contact surface reduces friction during fine adjustments. Compatible with ISO 15407-1 standard actuators.
- Cylinder stroke fine-tuning in CNC tool changers
- Position calibration of semiconductor wafer handlers
- Printing press roller gap adjustment systems
- Robotic end-effector alignment mechanisms
- Medical imaging equipment positioning stages
Installation protocol:
Apply thread-locking compound (medium strength) on mounting threads before installation.
Perform final torque adjustment after 3-5 full thermal cycles in operational environment.
Re-torque check recommended every 2,000 operating hours.
| Property | Property Value |
|---|---|
| sku | F-JCK50X15LM |
| Bore Diameter | <50mm> |
| Adjustment Angle | 15° |
