Airtac F-JCK-LM Adjustment Screw F-JCK50X30LM
AirTAC F-JCK-LM Adjusting Screw F-JCK50X30LM Technical Specifications
- Full model designation: F-JCK50X30LM
- Thread specification: M50×1.5 metric fine thread
- Effective adjustment length: 30mm (±0.2mm)
- Total screw length: 55mm (including mounting features)
- Material composition: SCM435 alloy steel (chromium-molybdenum)
- Surface treatment: Black oxide coating (5-8μm thickness)
- Locking mechanism: Double-nut anti-loosening system
- Max axial load capacity: 12kN (static), 8kN (dynamic)
- Temperature tolerance: -30℃ to 120℃
- Weight: 428g ±5g (with locking components)
- Package dimensions: 85mm(L) × 65mm(W) × 25mm(H)
- Thread engagement tolerance: Class 6g/6H per ISO 965-1
- Surface hardness: HRC 28-32 after heat treatment
Precision-engineered position adjustment screw with enhanced anti-vibration properties, featuring a patented dual-contact locking system that maintains positional accuracy under cyclic loading. The tapered thread root design improves fatigue resistance by 40% compared to standard ACME threads.
- Industrial robot joint position calibration
- CNC machine tool stroke limit adjustment
- Hydraulic cylinder cushioning mechanism tuning
- Automated assembly line fixture positioning
- Plastic injection molding machine platen alignment
Installation protocol:
Apply molybdenum disulfide grease (NLGI #2) on threads before installation.
Use calibrated torque wrench (recommended 120-150N·m) for final tightening.
Perform positional verification after 24hrs of initial operation.
| Property | Property Value |
|---|---|
| sku | F-JCK50X30LM |
| Bore Diameter | <50mm> |
| Adjustment Angle | <30°> |
