Airtac F-JCK-LM Adjustment Screw F-JCK50X45LM
AirTAC F-JCK-LM Adjusting Screw F-JCK50X45LM Technical Details
- Full model designation: F-JCK50X45LM
- Thread specification: M50×1.5 precision metric thread
- Adjustment stroke: 45mm (±0.2mm tolerance)
- Locking torque range: 1.2-3.5 N·m (adjustable)
- Body material: Chrome-plated carbon steel (SCM435 equivalent)
- Surface treatment: Black oxide coating (8-12μm thickness)
- Operating temperature: -30℃ to 120℃
- Vibration resistance: 10-55Hz @ 1.5mm amplitude
- Weight: 620g ±2% (including locking nut)
- Dimensions: 78mm(L) × 50mm(Ø) × 50mm(Hex width)
- IP rating: IP54 (dust protected, splash resistant)
- Compatible lubricant: Lithium soap-based grease
Heavy-duty mechanical adjuster with progressive locking mechanism, featuring wear-resistant chromium plating and anti-backlash design. The dual-engagement thread profile ensures vibration-resistant positioning, while the hexagonal body allows tool-free manual adjustments. Rated for 100,000+ adjustment cycles.
- Pneumatic cylinder stroke fine-tuning systems
- Injection molding machine platen parallelism adjustment
- Conveyor belt tensioning mechanisms
- Robotic end effector positioning calibration
- CNC machine tool limit stop configurations
Installation protocol:
Apply initial lubrication to thread engagement area before first use.
For optimal performance, retorque after 50 operating cycles.
Use 17mm combination wrench for body stabilization during adjustment.
| Property | Property Value |
|---|---|
| sku | F-JCK50X45LM |
| Bore Diameter | <50mm> |
| Adjustment Angle | <45 degrees> |
