Airtac F-JCK-LM Adjustment Screw F-JCK50X60LM
AirTAC F-JCK-LM Adjustment Screw F-JCK50X60LM Technical Details
- Full Model: F-JCK50X60LM
- Series: F-JCK-LM precision adjustment series
- Material: Chrome-plated carbon steel (SCM435 equivalent)
- Thread Specification: M50×1.5 coarse pitch metric thread
- Effective Travel: 60mm (±5mm adjustable range)
- Torque Rating: 3.5-4.2 N·m (recommended operating torque)
- Surface Treatment: Double-layer nickel plating (8-12μm thickness)
- Hardness: HRC 28-32 core / HRC 45-50 surface
- Weight: 152g ±2g
- Dimensions: Ø50mm (max diameter) × 60mm (total length)
- Mounting Hole: M6 threaded (4x symmetrical positions)
- Temperature Tolerance: -30℃ to 120℃ (lubricated condition)
- Anti-Corrosion: 96hr neutral salt spray test passed
Precision-ground adjustment screw with micron-level positioning accuracy (±0.02mm repeatability), featuring anti-backlash design through spring-loaded thread engagement. The chromium-nickel composite coating provides exceptional wear resistance, achieving over 50,000 cycles at full load. Includes integrated locknut with nylon insert for vibration resistance.
- Z-axis fine adjustment in CNC machining centers
- Parallelism calibration for semiconductor wafer stages
- Press machine die height micro-adjustment systems
- Robotic end effector position calibration
- Optical lens focusing mechanisms
Installation protocol:
Apply MoS2-based grease to threads before initial use. Torque locknut to 6.5-7.2 N·m
after position setting. Perform backlash compensation every 500 operating hours.
| Property | Property Value |
|---|---|
| sku | F-JCK50X60LM |
| Bore Diameter | <50mm> |
| Adjustment Angle | <60°> |
