Airtac F-JCK-LM Adjustment Screw F-JCK50X75LM
AirTAC F-JCK-LM Adjustment Screw F-JCK50X75LM Technical Specifications
- Full model number: F-JCK50X75LM
- Series: F-JCK-LM precision adjustment series
- Body material: Carbon steel with nickel plating
- Thread specification: M8×1.25 fine pitch
- Total length: 75±0.2mm
- Effective adjustment range: 0-12mm stroke
- Locking nut diameter: 14mm
- Operating torque: 0.5-2.0 N·m (recommended)
- Surface hardness: HV300-400
- Temperature tolerance: -30℃ to 120℃
- Corrosion resistance: 96hrs salt spray test passed
- Weight: 215g ±5g
- Dimensions: 50mm(Ø) × 75mm(L) × 14mm(Hex width)
Precision-machined micro-adjustment screw with graduated scale (0.5mm increments) for accurate positional calibration. Features dual-stage locking mechanism with integrated jam nut and anti-vibration rubber washer. The knurled grip surface ensures slip-resistant operation even with oily hands.
- Pneumatic cylinder stroke fine-tuning in assembly lines
- Mold height adjustment for injection molding machines
- Sensor position calibration in automated test equipment
- Printing press roller gap adjustment systems
- Robotic end-effector alignment mechanisms
Installation protocol:
Apply thread-locking compound (medium strength) before final tightening.
Perform quarter-turn back after full engagement to prevent over-tensioning.
Re-torque after 48hrs of initial operation.
| Property | Property Value |
|---|---|
| sku | F-JCK50X75LM |
| Bore Diameter | <50mm> |
| Adjustment Angle | 75° |
