Airtac F-JCK-LM Adjustment Screw F-JCK50X90LM
AirTAC F-JCK-LM Adjustment Screw F-JCK50X90LM Technical Details
- Full Model: F-JCK50X90LM
- Series: Precision Fine Adjustment Screw (Locking Mechanism Type)
- Material: Carbon Steel with Nickel Plating (Surface Hardness HRC 45-50)
- Thread Specification: M50×1.5 Metric Fine Thread
- Effective Adjustment Range: ±5mm
- Locking Torque: 12-15 N·m (Using Standard Hex Key)
- Installation Torque: 25-30 N·m (For Base Mounting)
- Weight: 850g ±3% (With All Accessories)
- Dimensions:
- Total Length: 90mm
- Threaded Portion Length: 65mm
- Major Diameter: 50mm
- Hex Nut Size: 55mm AF
- Mounting Hole Spacing: 75mm (Center-to-Center)
- Temperature Tolerance: -30℃ to 120℃ (Continuous Operation)
- Surface Roughness: Ra 1.6μm (Machined Contact Surfaces)
- Anti-Corrosion Standard: 96hrs Neutral Salt Spray Test Passed
Heavy-duty micro-adjustment screw with dual-stage locking mechanism, featuring wear-resistant chromium-molybdenum alloy core and precision ground threads (ISO 2 tolerance grade). The knurled edge allows tool-free coarse adjustment, while the integrated hex socket enables 0.01mm-level fine tuning. Includes built-in dust shield for contamination prevention.
- CNC fixture Z-axis depth calibration
- Injection molding machine platen parallelism adjustment
- Robotic end-effector positional fine-tuning
- Stamping press die height compensation
- Optical equipment focusing mechanism
Installation Protocol:
Apply medium-strength thread locker (Loctite 243 recommended) on mounting threads.
Perform initial run-in adjustment with 3 full clockwise rotations followed by
1/4 counterclockwise retreat to ensure proper thread engagement. Re-torque after
48 hours of operation.
| Property | Property Value |
|---|---|
| sku | F-JCK50X90LM |
| Bore Diameter | <50mm> |
| Adjustment Angle | <90°> |
