Airtac F-JCK-LM Adjustment Screw F-JCK63X105LM
AirTAC F-JCK-LM Fine Adjustment Screw F-JCK63X105LM Technical Details
- Model: F-JCK63X105LM
- Type: Precision mechanical adjustment screw with locking mechanism
- Material: Carbon steel with nickel plating
- Thread specification: M6×1.0 pitch
- Total length: 105±0.5mm
- Effective thread length: 63mm
- Adjustment torque range: 0.8-2.5 N·m
- Locking nut torque: 1.2-3.0 N·m
- Mounting hole diameter: 6.2-6.5mm
- Surface hardness: HV 550-650
- Operating temperature: -30℃ to +120℃
- Weight: 118±5g
- Dimensions: 105mm(L) × 12mm(Dia.) × 12mm(Hex head width)
High-precision adjustment screw with dual-stage locking system, featuring wear-resistant threads and anti-vibration design. The hexagonal base allows tool-assisted micro-adjustments (0.05mm precision) while maintaining position stability under 15N lateral force. Includes integrated dust-resistant O-ring (NBR material) for industrial environments.
- Pneumatic cylinder stroke fine-tuning
- CNC machine tool limit position calibration
- Automated assembly line fixture positioning
- Semiconductor equipment Z-axis adjustment
- Robotic end effector alignment systems
Installation guidelines:
Apply lithium-based grease to threads before initial use.
Perform final torque adjustment after 3-5 break-in cycles.
Maximum 120 RPM during installation.
Re-torque after 48 hours of continuous operation.
| Property | Property Value |
|---|---|
| sku | F-JCK63X105LM |
| Bore Diameter | 63mm |
| Adjustment Angle | 105° |
