Airtac F-JCK-LM Adjustment Screw F-JCK63X120LM
$16.25
Regular price
$23.75
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
F-JCK63X120LM
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
Product Category: Welding Clamping Cylinder
Brand: AirTAC
Series: F-JCK-LM Adjusting Screw
A precision-engineered pneumatic actuation component designed for welding fixture applications. The F-JCK-LM series features a robust threaded adjustment mechanism with fine-tuning capability for precise stroke control and position calibration in automated welding systems. Its hardened steel construction ensures wear resistance under high-cycle operations, while the anti-corrosion surface treatment guarantees performance stability in harsh industrial environments. Integrated with standardized mounting interfaces (ISO 6432 compliant) for seamless integration with welding jigs and robotic arms. Optional locking nut configuration prevents unintended positional drift during continuous vibration exposure. Typical applications include spot welding positioners, assembly line clamping fixtures, and CNC welding automation setups.
Installation protocol:
Apply Molykote G-rapid grease to threads before installation.
Use calibrated torque wrench for final tightening. Perform
clockwise rotation for extension, counter-clockwise for retraction.
Re-torque after 50 operational cycles.
AirTAC F-JCK-LM Adjusting Screw F-JCK63X120LM Technical Details
- Model: F-JCK63X120LM
- Type: Precision mechanical adjusting screw with locknut
- Material: Carburized steel (SCM435 equivalent)
- Surface treatment: Black oxide coating (5-8μm)
- Thread specification: M10×1.25 fine pitch
- Effective adjustment range: ±3mm
- Maximum load capacity: 2,500N (static)/1,800N (dynamic)
- Rotation torque: 0.8-1.2 N·m (recommended)
- Locknut torque: 4.5-5.5 N·m
- Weight: 327g ±5g
- Dimensions: 63mm (Diameter) × 120mm (Total length)
- Operating temperature: -30℃ to 120℃
- Vibration resistance: ≤15m/s² (10-2000Hz)
- Compatibility: Designed for SDA/SUJ series cylinders
High-precision mechanical adjuster with anti-backlash design, featuring wear-resistant carbide tip for repetitive positioning. The double-nut locking system ensures zero drift under vibration. Hardened shank (HRC58-62) prevents thread deformation during high-load applications.
Typical Applications:
- Stroke adjustment in pneumatic cylinder systems
- Position calibration for robotic end effectors
- Clamping force regulation in assembly fixtures
- Z-axis fine-tuning in CNC tooling setups
- Shock absorption systems in press machinery
Installation protocol:
Apply Molykote G-rapid grease to threads before installation.
Use calibrated torque wrench for final tightening. Perform
clockwise rotation for extension, counter-clockwise for retraction.
Re-torque after 50 operational cycles.
| Property | Property Value |
|---|---|
| sku | F-JCK63X120LM |
| Bore Diameter | 63mm |
| Adjustment Angle | 120° |
