Airtac F-JCK-LM Adjustment Screw F-JCK63X135LM
$16.25
Regular price
$23.75
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
F-JCK63X135LM
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
Product Category: Welding Clamping Cylinder
Brand: AirTAC
Series: F-JCK-LM Adjusting Screw
A precision-engineered pneumatic actuation component designed for welding fixture applications. The F-JCK-LM series features a robust threaded adjustment mechanism with fine-tuning capability for precise stroke control and position calibration in automated welding systems. Its hardened steel construction ensures wear resistance under high-cycle operations, while the anti-corrosion surface treatment guarantees performance stability in harsh industrial environments. Integrated with standardized mounting interfaces (ISO 6432 compliant) for seamless integration with welding jigs and robotic arms. Optional locking nut configuration prevents unintended positional drift during continuous vibration exposure. Typical applications include spot welding positioners, assembly line clamping fixtures, and CNC welding automation setups.
Maintenance guidance:
Apply lithium-based grease (NLGI #2) to threads quarterly in high-cycle applications.
Use torque wrench for final locking to prevent thread deformation. Avoid overtightening beyond 2.5N·m.
AirTAC F-JCK-LM Series Adjusting Screw F-JCK63X135LM Technical Details
- Full model designation: F-JCK63X135LM
- Series: Fine adjustment locking mechanism (LM) type
- Thread specification: M6 × 1.0 pitch
- Effective adjustment range: ±3mm
- Total length: 135mm (±0.2mm tolerance)
- Threaded portion length: 25mm
- Hexagon socket size: 3mm (ISO 4762 standard)
- Material: SCr420 alloy steel (JIS G4105)
- Surface treatment: Black oxide coating (5-8μm thickness)
- Hardness: HRC 52-56 after carburizing
- Locking torque: 1.2-1.8 N·m (recommended)
- Weight: 48g (±2g)
- Dimensions: 135mm(L) × 6mm(thread diameter) × 10mm(flange diameter)
- Temperature tolerance: -30℃ to 120℃
- Corrosion resistance: 96hrs salt spray test passed
Precision-ground micro-adjustment screw with anti-backlash locking collar, featuring wear-resistant chromium-molybdenum steel construction. The diamond-knurled grip surface ensures positive control during manual adjustments. Compatible with standard 3mm hex keys (not included).
Installation & Typical Applications:
- Precision stroke adjustment in AIRTAC CJ2 series cylinders
- Z-axis calibration in CNC machine tool limit switches
- Conveyor belt tensioning system fine-tuning
- Robotic end effector position calibration
- Optical equipment focus adjustment mechanisms
Maintenance guidance:
Apply lithium-based grease (NLGI #2) to threads quarterly in high-cycle applications.
Use torque wrench for final locking to prevent thread deformation. Avoid overtightening beyond 2.5N·m.
Designed for use with:
- AIRTAC CJ2B series compact cylinders
- Magnetic switch mounting brackets (F-JCK-MAG adapter required)
- ISO 21287 standard pneumatic actuators
| Property | Property Value |
|---|---|
| sku | F-JCK63X135LM |
| Bore Diameter | 63mm |
| Adjustment Angle | 135° |
