Airtac F-JCK-LM Adjustment Screw F-JCK63X30LM
AirTAC F-JCK-LM Adjusting Screw F-JCK63X30LM Technical Details
- Full model: F-JCK63X30LM
- Series: Fine adjustment locking mechanism (LM) series
- Thread specification: M6×1.0 pitch
- Effective length: 30mm ±0.2mm
- Total length: 34.5mm (including locknut)
- Material: Carbon steel with zinc-nickel plating
- Locknut torque: 1.2-1.5 N·m (recommended)
- Operating temperature: -30℃ to 120℃
- Surface hardness: HV 450-550
- Weight: 18.7g ±0.5g
- Dimensions: 6mm(D) × 34.5mm(L) × 10mm(W) across flats
- Hex wrench size: 5mm (for adjustment)
- Vibration resistance: ≤15Hz frequency, 2.5mm amplitude
Precision mechanical adjustment screw with anti-loosening locknut, featuring dual-stage micro-adjustment capability (±0.05mm repeatability). The diamond-knurled grip surface ensures secure handling even with oil-contaminated fingers. Includes integrated dust shield collar for particle protection.
- CNC machine tool backlash compensation
- Robotic end-effector position calibration
- Optical equipment focus adjustment mechanisms
- Conveyor belt tensioning systems
- Semiconductor wafer stage alignment
Installation protocol:
Apply medium-strength thread locker (LOCTITE 243 recommended) on lower 2/3 of threads.
Tighten locknut while maintaining 0.1-0.3mm gap between screw shoulder and mounting surface.
Re-torque after 24hrs of initial installation.
| Property | Property Value |
|---|---|
| sku | F-JCK63X30LM |
| Bore Diameter | 63mm |
| Adjustment Angle | <30°> |
