Airtac F-JCK-LM Adjustment Screw F-JCK63X45LM
$16.25
Regular price
$23.75
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
F-JCK63X45LM
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
Product Category: Welding Clamping Cylinder
Brand: AirTAC
Series: F-JCK-LM Adjusting Screw
A precision-engineered pneumatic actuation component designed for welding fixture applications. The F-JCK-LM series features a robust threaded adjustment mechanism with fine-tuning capability for precise stroke control and position calibration in automated welding systems. Its hardened steel construction ensures wear resistance under high-cycle operations, while the anti-corrosion surface treatment guarantees performance stability in harsh industrial environments. Integrated with standardized mounting interfaces (ISO 6432 compliant) for seamless integration with welding jigs and robotic arms. Optional locking nut configuration prevents unintended positional drift during continuous vibration exposure. Typical applications include spot welding positioners, assembly line clamping fixtures, and CNC welding automation setups.
Installation protocol:
Apply MoS₂-based grease to threads before initial use.
Tighten locknut clockwise while holding screw position.
Maximum 500μm adjustment resolution achievable through differential threading.
AirTAC F-JCK-LM Adjusting Screw F-JCK63X45LM Technical Details
- Full model: F-JCK63X45LM
- Type: Precision adjustment screw with locknut
- Thread specification: M6×0.75
- Effective thread length: 45mm
- Total length: 63mm
- Major diameter: 6mm ±0.1
- Pitch tolerance: ±0.02mm
- Material: Carbon steel (SCM435 equivalent)
- Surface treatment: Nickel plating (5-8μm)
- Locknut torque: 2.5-3.0 N·m
- Operating temperature: -30℃ to 120℃
- Weight: 48g ±2g
- Dimensions: 63mm(L) × 14mm(Dia.) × 14mm(Hex width)
Hardened adjustment screw with anti-backlash design, featuring dual-component construction with steel core and nylon locking element. The reverse-threaded locknut maintains precise positioning under vibration. Compatible with ISO 4028 metric fine thread standards.
Typical Applications:
- Pneumatic cylinder stroke micro-adjustment
- Linear guide preload calibration
- Injection molding machine nozzle pressure regulation
- Semiconductor equipment Z-axis fine-tuning
- Robotic end effector alignment systems
Installation protocol:
Apply MoS₂-based grease to threads before initial use.
Tighten locknut clockwise while holding screw position.
Maximum 500μm adjustment resolution achievable through differential threading.
| Property | Property Value |
|---|---|
| sku | F-JCK63X45LM |
| Bore Diameter | 63mm |
| Adjustment Angle | <45 degrees> |
