Airtac F-JCK-LM Adjustment Screw F-JCK63X60LM
$16.25
Regular price
$23.75
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
F-JCK63X60LM
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
Product Category: Welding Clamping Cylinder
Brand: AirTAC
Series: F-JCK-LM Adjusting Screw
A precision-engineered pneumatic actuation component designed for welding fixture applications. The F-JCK-LM series features a robust threaded adjustment mechanism with fine-tuning capability for precise stroke control and position calibration in automated welding systems. Its hardened steel construction ensures wear resistance under high-cycle operations, while the anti-corrosion surface treatment guarantees performance stability in harsh industrial environments. Integrated with standardized mounting interfaces (ISO 6432 compliant) for seamless integration with welding jigs and robotic arms. Optional locking nut configuration prevents unintended positional drift during continuous vibration exposure. Typical applications include spot welding positioners, assembly line clamping fixtures, and CNC welding automation setups.
Installation protocol:
Apply 2-3 drops of ISO VG32 hydraulic oil on threads before initial use.
Final tightening torque should not exceed 1.5N·m to prevent thread deformation.
Re-tighten after first 48hrs of operation.
AirTAC F-JCK-LM Adjustment Screw F-JCK63X60LM Technical Details
- Full model designation: F-JCK63X60LM
- Adjustment type: Fine thread precision adjustment
- Body material: Carbon steel with nickel plating
- Thread specification: M6×1.0 pitch
- Total length: 60±0.5mm
- Effective stroke: 20mm
- Locking torque: 0.5-1.2 N·m
- Operating temperature: -30℃ to 120℃
- Surface hardness: HV300-400
- Weight: 84±2g
- Dimensions: 63mm(L) × 18mm(W) × 18mm(H)
- Knurled handle diameter: 12mm
- Compatible cylinder series: SC/SU/MI series standard cylinders
High-precision adjustment screw with anti-corrosion coating, featuring a diamond-pattern knurled grip for tool-free manual adjustments. The double-nut locking mechanism prevents positional drift under vibration. Rated for 50,000+ adjustment cycles with ±0.01mm repeatability.
Primary Applications:
- Cushion adjustment for pneumatic cylinder end stops
- Position fine-tuning in conveyor guide systems
- Mechanical stopper calibration in injection molding machines
- Z-axis depth control in CNC fixtures
- Packaging machine pusher alignment
Installation protocol:
Apply 2-3 drops of ISO VG32 hydraulic oil on threads before initial use.
Final tightening torque should not exceed 1.5N·m to prevent thread deformation.
Re-tighten after first 48hrs of operation.
| Property | Property Value |
|---|---|
| sku | F-JCK63X60LM |
| Bore Diameter | 63mm |
| Adjustment Angle | <60°> |
