Airtac F-JCK-LM Adjustment Screw F-JCK63X75LM
AirTAC F-JCK-LM Adjusting Screw F-JCK63X75LM Technical Details
- Full Model: F-JCK63X75LM
- Series: F-JCK-LM Precision Adjustment Series
- Thread Specification: M6×1.0 Fine Pitch
- Adjustment Stroke: 0-8mm Graduated Scale
- Lock Nut Torque: 2.5-3.0 N·m (Precision Locking)
- Material Composition:
- Screw Body: SCr420 Alloy Steel
- Lock Nut: SUS304 Stainless Steel
- Knob: PA66+30%GF Composite
- Surface Treatment: Black Oxide Coating (Fe3O4)
- Operating Temperature: -30℃ to 120℃
- Weight: 118g ±2g (Precision Measured)
- Dimensions:
- Total Length: 75mm
- Body Diameter: Φ63mm
- Knob Height: 18mm
- Mounting Base: 42mm×42mm Square
- Vibration Resistance: 10-55Hz @ 1.5mm Amplitude
Micro-adjustment screw with anti-backlash design, featuring laser-etched calibration marks for precision positioning in pneumatic cylinder applications. The thermal-stable construction maintains dimensional stability across temperature variations. Includes integrated dust-resistant O-ring (NBR material) for contamination protection.
- End-of-stroke fine-tuning in SMC-type cylinders
- Packaging machine stopper position calibration
- Robotic arm repeatability adjustment
- Medical device actuator zero-point setting
- Semiconductor equipment Z-axis compensation
Adjustment Protocol:
Loosen lock nut with 10mm wrench (CW), rotate adjustment knob (0.05mm per division)
using calibrated torque driver (max 1.2N·m), then re-tighten lock nut while maintaining
screw position. Perform backlash check after 3 thermal cycles.
| Property | Property Value |
|---|---|
| sku | F-JCK63X75LM |
| Bore Diameter | 63mm |
| Adjustment Angle | 75° |
