Airtac F-JCK-LM Adjustment Screw F-JCK63X90LM
AirTAC F-JCK-LM Adjusting Screw F-JCK63X90LM Technical Details
- Full model designation: F-JCK63X90LM
- Thread specification: M10×1.25 precision ground
- Material: Case-hardened SCM435 alloy steel (HRC 28-32)
- Effective adjustment range: 0-15mm ±0.2mm repeatability
- Maximum torque capacity: 18 N·m
- Temperature tolerance: -30℃ to 120℃
- Surface treatment: Black oxide coating (8-12μm)
- Locking mechanism: Double-nut anti-vibration design
- Installation type: Through-hole mounting (Ø12mm clearance)
- Compatible series: FG/SC/SD standard cylinders
- Weight: 220g ±5%
- Dimensions: 90mm(L) × Ø63mm (knurled grip section Ø18mm)
Precision mechanical stop screw with vibration-resistant locking, engineered for micron-level position adjustment in pneumatic cylinder systems. Features wear-resistant chromium-molybdenum alloy construction with corrosion-inhibiting coating. Includes integrated O-ring (NBR 70±5 Shore A) for dust prevention.
- Stroke adjustment in injection molding machine ejectors
- End position fine-tuning for automated packaging lines
- Buffer regulation in material handling actuators
- Position limit setting for robotic assembly units
Installation protocol:
Apply 2-3 drops of ISO VG32 hydraulic oil on threads before installation.
Use calibrated torque wrench (12-15N·m) for final tightening. Re-torque
after 50 operation cycles. Avoid overtightening beyond yield point.
| Property | Property Value |
|---|---|
| sku | F-JCK63X90LM |
| Bore Diameter | 63mm |
| Adjustment Angle | <90°> |
