Airtac F-JCK-LM Adjustment Screw F-JCK80X105LM
AirTAC F-JCK-LM Series Adjusting Screw F-JCK80X105LM Technical Details
- Full model designation: F-JCK80X105LM
- Product type: Precision mechanical adjusting screw (Locking type)
- Thread diameter: M80 coarse pitch metric thread
- Effective thread length: 105mm ±0.2mm
- Total length: 135mm (including adjustment head)
- Major diameter: 80mm
- Pitch: 3mm
- Material: SCM435 alloy steel (chromium-molybdenum)
- Surface treatment: Black oxide coating + anti-corrosion oil film
- Hardness: 32-38 HRC after heat treatment
- Load capacity: 12,500N static load / 8,200N dynamic load
- Operating temperature: -30℃ to 120℃
- Weight: 1,850g ±2%
- Dimensions: 135mm(L) × 80mm(W) × 80mm(H)
- Locking torque: 120-150N·m (using included hex key)
- Mounting interface: ISO 7438 compliant flange base
- Vibration resistance: ≤5G acceleration (10-2000Hz)
Heavy-duty precision adjustment mechanism with integrated locking function, featuring wear-resistant dual-contact surfaces and anti-backlash design. The chromium-molybdenum alloy construction withstands high cyclic loads while maintaining positional accuracy. Includes integrated dust shield and lubrication ports for extended maintenance intervals.
- Injection molding machine platen parallelism adjustment
- CNC machine tool backlash compensation systems
- Hydraulic press die height fine-tuning mechanisms
- Automated assembly line fixture positioning
- Wind turbine pitch control linkages
Installation protocol:
Apply MOBILITH SHC 100 grease to thread surfaces before initial use.
Use torque wrench with 12mm hex socket for final locking.
Re-torque after first 50 operating cycles.
| Property | Property Value |
|---|---|
| sku | F-JCK80X105LM |
| Bore Diameter | 80 mm |
| Adjustment Angle | 105° |
