Airtac F-JCK-LM Adjustment Screw F-JCK80X120LM
AirTAC F-JCK-LM Adjustment Screw F-JCK80X120LM Technical Details
- Model: F-JCK80X120LM
- Type: Fine-pitch mechanical adjustment screw
- Material: Carbon steel (SCM435 equivalent)
- Surface treatment: Black oxide coating with anti-corrosion oil
- Thread diameter: M8×1.25
- Effective thread length: 120mm
- Total length: 140±0.5mm
- Hex socket size: 5mm (Allen key drive)
- Adjustment range: 0-15mm linear travel
- Max load capacity: 2,500N (static), 1,800N (dynamic)
- Operating torque: 1.2-2.0N·m (lubricated condition)
- Weight: 328±5g
- Dimensions: 140mm(L) × 16mm(Ø head) × 8mm(Ø threaded shaft)
- Temperature range: -30℃ to 120℃
- Vibration resistance: ≤15Hz frequency, 2mm amplitude
Precision-ground adjustment screw with self-locking thread design, featuring wear-resistant trapezoidal thread profile for micron-level positioning accuracy. The knurled grip surface enhances torque application, while the through-hole design allows integration with position sensors. Includes built-in dust shield at base thread connection.
- Pneumatic cylinder stroke fine-tuning mechanisms
- CNC machine tool limit stop adjustment
- Conveyor belt tensioning systems
- Injection molding machine platen parallelism calibration
- Robotic end-effector positioning calibration
Installation protocol:
Apply MOBILUX EP2 grease to threads before initial use.
Locking nut (not included) must be torqued to 3.5N·m±10% after adjustment.
Avoid over-tightening beyond 4N·m to prevent thread deformation.
| Property | Property Value |
|---|---|
| sku | F-JCK80X120LM |
| Bore Diameter | 80 mm |
| Adjustment Angle | 120° |
