Airtac F-JCK-LM Adjustment Screw F-JCK80X135LM
AirTAC F-JCK-LM Adjusting Screw F-JCK80X135LM Technical Details
- Full model designation: F-JCK80X135LM
- Series: Fine adjustment lock mechanism (LM) series
- Material: SUS304 stainless steel body + CR12MoV alloy steel tip
- Surface treatment: Non-electrolytic nickel plating (3-5μm thickness)
- Thread specification: M8×1.25 precision ground thread
- Adjustment range: ±5mm (±0.2") axial displacement
- Locking torque: 3.5N·m (30.9 lb-in) maximum
- Weight: 450g ±2% (0.99 lbs)
- Dimensions: 80mm(Ø) × 135mm(L) (3.15" × 5.31")
- Operating temperature: -30℃ to 150℃ (-22°F to 302°F)
- Surface hardness: HRC52-56 at contact surfaces
- Radial play: ≤0.02mm (0.0008")
- Repeat positioning accuracy: ±0.01mm (0.0004")
Precision-ground micro-adjustment screw with dual-stage locking mechanism, featuring anti-backlash design for high-load positioning systems. The diamond-cut threads provide smooth operation with 98% mechanical efficiency. Corrosion-resistant construction with IP67 equivalent protection (non-certified).
- CNC machine tool backlash compensation systems
- Lithography machine Z-axis fine adjustment
- Robotic end effector positioning calibration
- Semiconductor wafer stage alignment mechanisms
- Precision die-cutting machine pressure adjustment
Installation protocol:
Apply MOS2-based grease to threads before initial use.
Use 8mm hex wrench for coarse adjustment and 3mm Allen key for final locking.
Maximum side load capacity: 250N (56.2 lbf) perpendicular to axis.
Re-lubrication: Every 5,000 cycles or 6 months in clean environments
| Property | Property Value |
|---|---|
| sku | F-JCK80X135LM |
| Bore Diameter | 80 mm |
| Adjustment Angle | 135° |
