Airtac F-JSI-CR Single Angled Lug Bracket Assembly Kit F-JSI80CR
AirTAC F-JSI-CR Single Inclined Ear Bracket Assembly - F-JSI80CR
- Model: F-JSI80CR
- Type: Angled mounting bracket kit (pre-assembled)
- Material: Aluminum alloy ADC12 + Steel
- Static load capacity: 1,500N (vertical), 800N (lateral)
- Mounting hole pattern: 32mm × 24mm rectangular array
- Thread specifications: M6×1.0 (4 holes)
- Surface treatment: Black anodized (aluminum) / Zinc-nickel plating (steel)
- Compatible rail types: SBR/SBR20, SBR30 series linear guides
- Included hardware: 4×M6×20 flange bolts, 8×shock-absorbing washers
- Weight: 385g ±5g (complete assembly)
- Dimensions: 82mm(L) × 68mm(W) × 34mm(H)
- Operating temperature: -40℃ to 120℃
- Vibration resistance: 5-2000Hz, 15G acceleration
Heavy-duty inclined bracket designed for precision alignment in linear motion systems. Features dual-material construction with corrosion-resistant coatings, combining aluminum's lightweight properties with steel reinforcement at stress points. Pre-installed with vibration-damping washers to minimize harmonic resonance in high-speed applications.
- CNC machine tool slide rail mounting
- Automated warehouse shuttle vertical stabilization
- 3D printer gantry reinforcement
- Semiconductor wafer handling robot bases
- Automotive assembly line positioning jigs
Installation protocol:
Apply 6-8Nm torque during bolt tightening using cross-pattern sequence.
Lubricate sliding contact surfaces with ISO VG32-grade grease monthly
in high-cyclic applications. Avoid direct exposure to cutting fluids.
