Airtac F-M-Y Connector Assembly Kit F-M5X080Y
$6.27
Regular price
$13.77
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
F-M5X080Y
Product type:
Tags:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
Product Name: Y-Type Pneumatic Cylinder Fitting Assembly Kit
Brand: AIRTC (Airtac International Group)
Series: F-M-Y
Description:
This F-M-Y series Y-connector assembly is engineered for precision pneumatic circuit connections in industrial automation systems. Featuring a corrosion-resistant brass construction with triple-port configuration (1 female / 2 male threaded ends), the compact fitting ensures secure branch line connections for pneumatic cylinders and actuator controls. Pre-assembled with OEM-grade sealing components and protective nylon sleeves, the kit delivers leak-proof performance under working pressures up to 1.0 MPa. Compliant with ISO 16030 pneumatic connection standards, it supports 6mm/8mm OD tubing for optimized airflow distribution in multi-cylinder arrangements.
Installation Guidance:
Cut hose end square (90°±2°) using dedicated cutter. Insert until tactile click is heard.
For permanent installations, apply 0.1ml silicone-free lubricant (ISO 6743-4 HM) on collar threads.
AirTAC F-M-Y Fitting Assembly Kit F-M5X080Y Technical Details
- Model Code: F-M5X080Y
- Series: F-M-Y Compact Push-in Fittings
- Thread Specification: M5x0.8 (Metric Fine)
- Hose ID: 4mm (Internal Diameter)
- Hose OD: 8mm (External Diameter)
- Effective Length: 80±1mm (Straight Section)
- Material Body: Brass with Nickel Plating
- Seal Material: NBR Rubber
- Hose Material: Polyurethane (PU)
- Operating Pressure: 0.5-1.5 MPa
- Temperature Range: -20℃ to +80℃
- Weight: 28g ±5% (Per Assembly)
- Dimensions: 80mm(L) × 8mm(W) × 8mm(H)
- Thread Engagement: ≥3 Full Turns
- Pull-out Force: ≥50N (Hose Retention)
Pre-assembled pneumatic fitting solution with integrated strain relief, designed for M5 port connections in confined spaces. Features anti-vibration collar and 360° rotatable fitting head for flexible installation angles. Compatible with ISO 12151-2 standard push-to-connect systems.
Typical Applications:
- Miniature pneumatic cylinders in SMT equipment
- Tool-free maintenance connections for CNC machine coolant lines
- Modular pneumatic circuit prototyping
- Medical device gas delivery systems
- Robotic end-effector tool switching mechanisms
Installation Guidance:
Cut hose end square (90°±2°) using dedicated cutter. Insert until tactile click is heard.
For permanent installations, apply 0.1ml silicone-free lubricant (ISO 6743-4 HM) on collar threads.
| Property | Property Value |
|---|---|
| sku | F-M5X080Y |
| Thread Pitch | <0.8 mm> |
| Thread Specification | <5mm> |
