Airtac F-M-Y Connector Assembly Kit F-M6X100Y
$6.27
Regular price
$13.77
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
F-M6X100Y
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
Product Name: Y-Type Pneumatic Cylinder Fitting Assembly Kit
Brand: AIRTC (Airtac International Group)
Series: F-M-Y
Description:
This F-M-Y series Y-connector assembly is engineered for precision pneumatic circuit connections in industrial automation systems. Featuring a corrosion-resistant brass construction with triple-port configuration (1 female / 2 male threaded ends), the compact fitting ensures secure branch line connections for pneumatic cylinders and actuator controls. Pre-assembled with OEM-grade sealing components and protective nylon sleeves, the kit delivers leak-proof performance under working pressures up to 1.0 MPa. Compliant with ISO 16030 pneumatic connection standards, it supports 6mm/8mm OD tubing for optimized airflow distribution in multi-cylinder arrangements.
Installation protocol:
Apply 2-3Nm torque during M6 thread engagement. For tubing insertion,
depress collet fully before inserting tube to end-stop. Perform
pressure test at 1.25× system pressure after installation.
AirTAC F-M-Y Fitting Assembly Kit F-M6X100Y Technical Details
- Full model designation: F-M6X100Y
- Product type: Pre-assembled M6-to-push-in fitting conversion kit
- Body material: Stainless steel (SUS303)
- Surface treatment: Electroless nickel plating (5-8μm thickness)
- Effective length: 100mm ±0.5mm (threaded portion to tube stop)
- Thread specifications: M6×1.0 external thread (ISO 262 metric fine)
- Tube compatibility: 6mm OD pneumatic tubing (PU/Nylon)
- Sealing element: EPDM O-ring (70±5 Shore A hardness)
- Operating temperature: -20℃ to +80℃ (continuous use)
- Pressure rating: 0.5-1.0 MPa (72-145 PSI)
- Weight: 85g ±3g (per assembled unit)
- Dimensions: 100mm(L) × 16mm(W) × 16mm(H)
- Package configuration: Bulk-packed with anti-corrosion paper (10 pcs/box)
- Vibration resistance: 10-55Hz, 1.5mm amplitude
- IP rating: IP40 (protected against 1mm+ particulates)
Factory-preassembled pneumatic transition fitting combining M6 male threads with push-to-connect tubing functionality. Features zero-clearance machining for vibration resistance in dynamic systems. The through-hole design maintains laminar airflow (Cv≈0.12) while preventing particulate accumulation.
Implementation Scenarios:
- Retrofitting legacy M6-threaded components to modular pneumatic systems
- Mobile equipment requiring vibration-resistant connections (AGVs, robotic arms)
- Cleanroom-compatible assembly lines (low particulate generation)
- Modular pneumatic teaching systems for technical education
- Packaging machinery with frequent tooling changes
Installation protocol:
Apply 2-3Nm torque during M6 thread engagement. For tubing insertion,
depress collet fully before inserting tube to end-stop. Perform
pressure test at 1.25× system pressure after installation.
Cycle Life: 50,000 connect/disconnect cycles or 10-year service life
(whichever comes first) when used within specified parameters. Replace O-ring
every 2 years in high-cycle applications.
| Property | Property Value |
|---|---|
| sku | F-M6X100Y |
| Thread Pitch | <1.0mm> |
| Thread Specification | <6mm> |
