Airtac F-MA-FA Front Flange Mounting Plate Kit F-MA50FA
AirTAC F-MA-FA Front Flange Mounting Plate Kit F-MA50FA Technical Details
- Model: F-MA50FA (Complete Kit)
- Type: Pre-assembled front flange mounting solution
- Material: Aluminum alloy AL6063-T5
- Surface treatment: Black anodized (12-15μm thickness)
- Mounting hole pattern: 4×M6 threaded holes (ISO 4762)
- Hole spacing: 50mm×50mm square pattern (±0.1mm tolerance)
- Rail compatibility: For 15mm width linear guide blocks
- Weight: 0.82kg (with all included hardware)
- Dimensions: 72mm(L) × 62mm(W) × 18mm(H)
- Load capacity: 800N static / 300N dynamic
- Operating temperature: -20℃ to 120℃
- Hardware included: M6×12 SHCS (4pcs), spring washers (4pcs), flat washers (4pcs)
- Anti-corrosion rating: 96hrs salt spray test passed
Precision-machined mounting plate designed for rigid coupling between linear guide blocks and machinery structures. Features vibration-damping properties through optimized mass distribution and includes anti-loosening hardware for industrial environments. The anodized surface provides both corrosion resistance and electrical insulation (withstand voltage: 500V DC).
- Linear motion systems in CNC machining centers
- Robotic arm base mounting in automotive assembly
- Precision alignment of optical inspection equipment
- High-frequency reciprocating mechanisms in packaging machinery
- Semiconductor wafer handling robots
Installation protocol:
Apply 2.5-3.5N·m torque using calibrated tool during assembly.
Clean mounting surface with isopropyl alcohol prior to installation.
Perform re-torque after 50 operational hours.
- Optimal pairing with AirTAC HGH15CA linear guides
- Requires M6 mounting screws (grade 8.8 or higher recommended)
- For vacuum environments, use supplementary silicone sealant
| Property | Property Value |
|---|---|
| sku | F-MA50FA |
