Airtac F-MF-FA Front Flange Mounting Plate Assembly Kit F-MF40FA
AirTAC F-MF-FA Front Flange Mounting Kit F-MF40FA Technical Details
- Complete Model: F-MF-FA-F-MF40FA
- Compatible Cylinder Series: ISO 15552 (DIN/VDMA 24552)
- Material: High-grade aluminum alloy AL6063-T5
- Surface Treatment: Hard anodized (25-30μm thickness)
- Color Code: Black (RAL 9005)
- Mounting Hole Pattern: 40mm center-to-center spacing
- Bore Diameter: 8mm precision reamed holes
- Thread Specification: M6×1.0 internal threads (4 places)
- Flatness Tolerance: ≤0.1mm/m
- Surface Roughness: Ra 1.6μm (machined contact surfaces)
- Weight: 650g ±2%
- Dimensions: 160mm(L) × 40mm(W) × 20mm(H)
- Operating Temp Range: -20°C to +80°C
- Corrosion Resistance: 96hr salt spray test compliant
- Vibration Resistance: 10-55Hz, 1.5mm amplitude
Precision-engineered front flange mounting solution designed for heavy-duty cylinder stabilization. Features CNC-machined alignment surfaces with dual anti-rotation pins (Ø4h7×8mm) and integrated vibration dampening design. Includes 4×Class 12.9 zinc-nickel plated mounting bolts with Nord-Lock washers for permanent installations.
- Robotic welding arm baseplate installations
- High-cycle packaging machine cylinder mounting (200+ cycles/min)
- Vertical axis guidance systems in CNC machinery
- Marine equipment installations requiring salt mist resistance
- Vibration-intensive press brake tooling setups
Installation protocol:
Apply 20-25Nm torque using calibrated wrench during assembly.
Use alignment jig AJP-40F for multi-unit installations.
Perform concentricity check with dial indicator (max 0.05mm TIR).
| Property | Property Value |
|---|---|
| sku | F-MF40FA |
