Airtac F-MF-LB Axial Fixing Frame Assembly Kit F-MF20LB
AirTAC F-MF-LB Series Axial Mounting Bracket Kit: F-MF20LB Full Specifications
- Model: F-MF20LB (Complete Kit)
- Type: Linear Guide Axial Fixation Bracket Set
- Material: High-grade carbon steel (SCM435 equivalent)
- Surface Treatment: Black oxide coating + anti-rust oil
- Compatible Rail: For 20mm width linear guides
- Mounting Type: Through-hole axial fixation
- Bolt Specifications: M6×12mm hex socket head screws (4 pcs included)
- Installation Torque: 5.0-6.0 N·m recommended
- Load Capacity: Max 2,500N static load (axial direction)
- Temperature Range: -30℃ to 120℃ (continuous operation)
- Weight: 0.48kg ±2% (complete kit)
- Dimensions: 62mm(L) × 34mm(W) × 28mm(H) (per bracket unit)
- Mounting Hole Spacing: 50mm center-to-center (longitudinal)
- Surface Roughness: Ra ≤3.2μm (contact surfaces)
- Protection Class: IP54 (assembled state)
Precision-engineered axial fixation solution for linear motion systems, featuring dual-point locking mechanism for enhanced vibration resistance. The black oxide layer provides corrosion protection while maintaining precise dimensional tolerances (±0.02mm). Includes pre-packed mounting hardware with thread-locking adhesive pre-applied.
- CNC machine tool slide unit stabilization
- 3D printer gantry axis reinforcement
- Automated warehouse shuttle positioning
- Semiconductor wafer handling robots
- Laser cutting head carriage fixation
Installation protocol:
Clean rail surface with IPA before mounting. Use torque wrench for even pressure distribution.
Re-torque after 24hrs of initial operation. Not suitable for angular misalignment compensation.
| Property | Property Value |
|---|---|
| sku | F-MF20LB |
