Airtac F-MF-Y Fitting Assembly Kit F-MF25Y
$9.27
Regular price
$16.77
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
F-MF25Y
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
Product Name: Pneumatic Cylinder Y-Type Fitting Assembly
Brand: AirTAC
Series: F-MF-Y
Specification Highlights:
- Material: Brass with Nickel Plating (Corrosion-Resistant Finish)
- Connection Type: Y-Branch Compact Design for Space-Constrained Installations
- Thread Standards: Metric/PT/NPT Thread Options Available (ISO 1179 Compliance)
- Pressure Rating: 0-1.0 MPa Operating Range
- Temperature Range: -5°C to 60°C (23°F to 140°F)
- Leakage Class: ≤0.1 NL/min (Class 4 per ISO 6952)
- Applications: Multi-circuit air distribution in pneumatic systems, compatible with PU/Nylon tubing
Package Configuration:
Pre-assembled kit includes:
1× Y-Type Fitting Body (Brass)
3× Sealing Elements (NBR O-Rings)
3× Thread Protectors
Installation Guide (EN/CN Bilingual)
Key Features:
① Precision CNC-machined thread interfaces ensuring bubble-tight seal
② 360° rotatable branch ports for flexible piping alignment
③ Compact footprint reduces system weight by 25% vs conventional fittings
④ Passed 1 million cycle endurance test (ISO 19973-1 certified)
Industry Compliance:
• RoHS 2011/65/EU compliant
• REACH SVHC < 0.1%
• Pneumatic Fitting Directive 2014/68/EU
Typical Use Cases:
- Modular pneumatic circuit branching in automation equipment
- Air preparation unit piping networks
- Robotic EOAT (End-of-Arm Tooling) pneumatic distribution
Note: For optimal performance with AirTAC SDA/SME series cylinders, recommend using with AS1200 series tube sleeves.
Installation protocol:
Cut tube square with dedicated cutter, deburr internally/externally,
insert fully until tactile click. Perform 1/4 turn test pull verification.
Maximum reconnection cycles: 15 times.
AirTAC F-MF-Y Series Fitting Kit F-MF25Y Technical Details
- Model: F-MF25Y (Complete Fitting Kit)
- Connection Type: Metric 24° Cone Compression Fitting
- Thread Specification: M12×1.5 (External Thread)
- Tube Compatibility: Ø25mm (1") OD Pneumatic Tubing
- Material Composition:
- Body: Lead-Free Brass CW617N
- Nut: Nickel-Plated Brass
- Collet: Spring Steel with Zinc-Nickel Coating
- Seal: HNBR O-Ring (Hydrogenated Nitrile)
- Pressure Rating: 0.05-1.6 MPa (7-232 PSI)
- Temperature Range: -20℃ to +120℃ (Continuous Use)
- Fluid Compatibility: Compressed Air, Inert Gases, Water/Oil Mist Lubricated Systems
- Vibration Resistance: ≤4.9m/s² (ISO 10816-3 Compliant)
- Weight: 215g ±5g (Complete Assembly)
- Dimensions: 62mm(L) × 32mm(W) × 32mm(H) (Maximum Projection)
- Certifications: RoHS 2011/65/EU, REACH SVHC Compliant
Heavy-duty push-to-connect fitting kit designed for high-flow pneumatic systems requiring vibration resistance. Features triple-seal technology with integrated collet grip ring and anti-rotation flats for tool-free maintenance. The electroless nickel plating provides corrosion protection in humid environments exceeding 85% RH.
Industrial Applications:
- CNC machine tool pneumatic clutches
- Automated material handling systems
- High-cycle packaging machinery air lines
- Foundry equipment compressed air distribution
- Railway braking system auxiliary connections
Installation protocol:
Cut tube square with dedicated cutter, deburr internally/externally,
insert fully until tactile click. Perform 1/4 turn test pull verification.
Maximum reconnection cycles: 15 times.
| Property | Property Value |
|---|---|
| sku | F-MF25Y |
