Description
Category: Cylinder Accessories
Brand: AIRTAC
Series: F-MI-FA Front Flange Mounting Plate Complete Kit
Precision-engineered front flange mounting solution for pneumatic cylinder systems, designed to ensure rigid fixation and alignment stability. Features corrosion-resistant steel construction with ISO-standard mounting interfaces. Includes pre-assembled components for rapid installation and compatibility with AIRTAC MI/FA series cylinders. Ideal for industrial automation applications requiring high repeatability and load-bearing performance.
Installation protocol:
Apply 0.6-0.8 N·m torque using calibrated tool.
Use thread locker (LOCTITE 243 recommended) in high-vibration environments.
Maintain 0.05mm maximum parallelism tolerance during alignment.
AirTAC F-MI-FA Front Flange Mounting Kit F-MI20FA Technical Details
- Model: F-MI20FA (Complete Kit)
- Compatible Cylinder Series: MI Series 20mm Bore
- Material: 6063-T5 Aluminum Alloy
- Surface Treatment: Hard Anodized (Matte Black)
- Mounting Pattern: ISO 15552 Standard Front Flange
- Bolt Hole Specifications: 4x M5 Threaded Holes (Depth 8mm)
- Center-to-Center Spacing: 32mm × 32mm Square Pattern
- Plate Thickness: 12mm ±0.1mm
- Weight: 285g (Including Mounting Hardware)
- Dimensions: 58mm(L) × 58mm(W) × 12mm(H)
- Operating Temperature: -20°C to 120°C
- Included Components:
- 1x Flange Plate
- 4x M5×16mm Stainless Steel Hex Bolts (A2-70)
- 4x M5 Flat Washers
- 4x M5 Spring Lock Washers
Precision-machined mounting solution designed for rigid fixation of MI series cylinders in space-constrained applications. Features vibration-resistant design with dual locking surfaces and corrosion-resistant coating. Includes anti-loosening hardware for industrial environments.
Typical Applications:
- Robotic arm joint articulation systems
- CNC machine tool clamping mechanisms
- Packaging line vertical lift actuators
- Cleanroom automation equipment
- Semiconductor handling robots
Installation protocol:
Apply 0.6-0.8 N·m torque using calibrated tool.
Use thread locker (LOCTITE 243 recommended) in high-vibration environments.
Maintain 0.05mm maximum parallelism tolerance during alignment.
